Main Feature:
• Intel 845GC+ICH4 Chipset
• Support Intel Socket478 Pentium4,Celeron Series CPU
• 2 x 184Pin DDR Slot Support 266/333 Memory
• 1 x 10/100M Ethernet LAN
• 2 x COM,4 x USB,2 x IDE
Introduction:
• PT-F845A is full-sized mother board supporting Intel Socket 478 Intel Pentium4 PICMG1.0 Full-size CPU
Card With Intel 845GC+ICH4 Chipset, having VGA and RJ45 10/100M LAN, 1*PS/2 KB/MS, also has internal
2*COM header, 4*USB2.0 header, 1*LPT header, 1*FDD. BUS is standard PICMG1.0 Full Size.
• It can be compatible with PICMG1.0 backplane. PT-F845A can be widely used for automation, industrial
acquisition data system, Intelligent transportation, Equipment application.
Specification:
CPU |
Support Intel Socket478 Pentium4,Celeron Series CPU |
Chipset |
Intel 845GC+ICH4 Chipset |
Memory |
2 x 184Pin slot,Support DDR 266/333 Memory Up to 2GB |
Storage |
2 x 40Pin IDE |
Expansion Slots |
Support 32Bit-PCI,16Bit- ISA |
|
Back Panel I/O Port |
1 x VGA |
1 x RJ45 10/100M LAN | |
1 x PS/2 KB&MS | |
|
Internal I/O Port |
2 x COM header |
4 x USB2.0 header | |
1 x LPT header | |
1 x FDD | |
Watchdog Timer |
255levels,1~255sec |
Bus Standard |
PICMG1.0 Full Size |
Power supply |
ATX/AT |
Dimension |
338 x 122mm |
Operating Temperature |
0°C ~ 60°C |
Storage Temperature |
-20°C ~ 80°C |
Storage Humidity |
5~90%@40°C(non-condensing) |
Ordering information
|
PT-F845A |
Intel 845GC+ICH4 full-sized mother board, with 1*VGA, 1*LAN, 1PS2 KB/MS. |
Product pictures:
