Main feature:
• Intel G41+ICH7 Chipset
• Support Intel LGA775 Core2 Duo,Core2 Quad,Celeron Series CPU
• 2 x DDR3 Slot Support 1066/1333 Memory
• 2 x 10/100/1000M Gigabit Ethernet LAN
• 1 x RS232,1 x RS232/485,8 x USB,4 x SATA, 1*IDE
Introduction :
• PT-FG41 is the full-sized mother board supporting Intel LGA775 Core2 Duo,Core2 Quad,Celeron Series
CPU with Intel G41+ICH7 Chipset, having 2*DDR3 slot, supporting DDR3 1066/1333 Memory, Max Up to 4GB, 4*SATA&1*IDE socket with expansion slot of 32bit-PCI and 16Bit-ISA.
• It has 1*VGA, 2* RJ45 10/100/1000M LAN(Optional), 1*PS/2 KB&MS with internal 1 x RS232,1 x RS232/485
header, 8 x USB2.0 header, 1 x LPT header, 1*IDE, 1 x AUDIO. It can completely be compatible with PICMG1.0 backplane.
• PT-FG41 can be widely used for automation, industrial acquisition data system, Intelligent transportation,
Equipment application.
Specification:
CPU |
Support Intel LGA775 Core2 Duo,Core2 Quad,Celeron Series CPU |
Chipset |
Intel G41+ICH7 Chipset |
Memory |
2 x DDR3 slot,Support DDR3 1066/1333 Memory Up to 4GB |
Storage |
4 x SATA, 1*IDE |
Expansion Slots |
Support 32Bit-PCI,16Bit-ISA |
|
Back Panel I/O Port |
1 x VGA |
2 x RJ45 10/100/1000M LAN(Optional) | |
1 x PS/2 KB&MS | |
|
Internal I/O Port |
1 x RS232,1 x RS232/485 header |
8 x USB2.0 header | |
1 x LPT header | |
1*IDE | |
1 x AUDIO(Optional) | |
Watchdog Timer |
255levels,1~255sec |
Bus Standard |
PICMG1.0 Full Size |
Power supply |
ATX/AT |
Dimension |
338 x 122mm |
Operating Temperature |
0°C ~ 60°C |
Storage Temperature |
-20°C ~ 80°C |
Storage Humidity |
5~90%@40°C(non-condensing) |
Ordering information:
PT- FG41 |
Intel G41+ICH7 full-sized mother board, W/1*VGA, 1*LAN, 1*PS2 KB/MS |
PT- FG41B |
Intel G41+ICH7 full-sized mother board, W/1*VGA, 2*LAN, 1*PS2 KB/MS |
product pictures:
More Products:
Shenzhen Pontron Technology Ltd we have dedicated in Industrial panel pc,Industrial LCD monitor,KVM, Industrial BOX pc,workstation,Mini pc in the worldwide market for 10 years. our products has the CE/EMC/FCC/ROHS certificate and the customers are all over the world.especially in USA, Europe, Australia and Asia.
Our dedicated team of engineers, production specialists, and administrative staff provide the best quality products available on the market.
We pride ourselves on our expertise in producing customized products. Through ODM/OEM production, you are assured of designs which will meet your exact specifications. Our innovative ideas in manufacturing which will make your products a leading seller on the market. this results in short period of develpoment time for projects.
In PONTRON, we have a qualified working team which includes senior level mechanical and electronic R&D engineers, OEM product/sales manager, ISO 9001 trained manufacturing personel, and an efficient logistics department. we have an average age of 30 years old, and the average working experience in the industrial computer field is more than 7 years.
PONTRON, is committed in prooviding quality, innovative products and technical support to our customers in a very cost effective manner. we like to grow with our customers.we believe customer satisfaction is the key to our growth and success. we work for your needs and your satisfaction is guaranteed.
Packaging: Duoble package 424mm(L) 348mm(W) 80mm(H) ;570mm(L) 430mm(W) 173mm(H).
Delivery time: Within 1day after order and samples are confirmed.
