automatic dispensing machine
Sepcification: automatic dispensing machine
| Travel RangeX/Y/Z |
300/300/100(mm) |
| Table Max Load |
10KG |
| Z Axis |
4.5KG |
| Moving SpeedXY/Z |
0.1-800/400(mm/sec) |
| Analytical Ability |
0.01mm/Axis |
| Repeatability |
±0.01mm/200mm |
| Program Recording Capacity |
1000 |
| Display |
5 Inch LCD |
| Motor |
Japan micro-level precision stepper motor |
| Moving Mode |
Point to point, Continuous line |
| Transmission |
Japanese belt,Precision linear guide |
| Motion Makeup Function |
3 Axis |
| Edit Mode |
Teach box or computer file input |
| I/O Signal |
6In puts 6 Out puts |
| Power |
AC 220V/350W |
| Operating Temperature |
5-40℃ |
| Operating Humidity |
20-90%(no condensation) |
| Size(mm) |
522 x 560 x 565 |
| Weight(kg) |
62.5 |
Features: automatic dispensing machine
1,Could be a particular dispensing operations, mechanized production
2.Simple and convenient to operate, high-speed precision
3.Program files can be uploaded/downloaded through U disk,easy to manage
4.Has control buttons on the needle, no external teaching is more convenient than similar products debugging
5,Used LCD 5-inch color screen display automatic dispensing machine
6,Does not cause noise pollution to production sites automatic dispensing machine
7,Enabling 3D dispensing systems, regardless of any comple shape and dispensing path can be accurately completed
8,Can be equipped with single-tube or pipe dispensing, improve efficiency in the realization of different glue or dispensing path
9,Used for in all kinds of demand dispensing industry, such as:general common UV plastic, silicon, EPOXY, red gum, paste,AB glue,
COB vinyl, conductive plastic, aluminum heat glue,instant glue,paste and other points glue, can be used on the D-series devices.
Applications: automatic dispensing machine
1,LED package automatic dispensing machine
2,Mobile phone plate coating or dispensing button
3,Speaker Dispensing
4,Dispensing sealing the battery case
5,The semiconductor package
6,Power component package
7,chip binding automatic dispensing machine
8,Fixed and protected PCB electronic components
9,LCD glass board package
Detail image: automatic dispensing machine
automatic dispensing machine
automatic dispensing machine
Partners: automatic dispensing machine
Sercive processing: automatic dispensing machine
