Help CenterFpc Soldering Fixtures Wave Soldering Carrier
Related Products
-
PCB Depaneling Machine CNC RouterUS$ 1 - 2MOQ: 1 Set -
V-cut Pcb Depaneling Machine Made in DongguanUS$ 1 - 3MOQ: 1 Set
-
FR4 Pcb Depaneling Machine With CE Certificate CWVC-1US$ 1,000 - 1,500MOQ: 1 Set
-
600mm PCB Separator MachineUS$ 1 - 5,000MOQ: 1 Set
-
Pcb Separating Machine New Launch MachineUS$ 1 - 3MOQ: 1 Set
Features and Benefits
Wave solder pallets offer many advantages to the cost conscious Process Engineer. These advantages can usually pay back in a few weeks with cost savings and improved yields. By deploying a double reflow process, you can maximize your yields through the wave solder process.
Other advantages are:
1 Eliminate flooding by masking open areas and preventing board sag.
2 Reduce second hand load parts and hand soldering.
3 Save thousands of dollars in Kapton tape and the labor to add and remove.
4 The composite materials thermally protect bottom side SMD’s from shock.
5 Mask BGA vias from the wave ensuring reliable solder joints.
6 Lead Free grade optical material for higher temperatures
Specification:
| Model | DurostoneCHP760 | DurostoneCAS761 | DurostoneCAG762 |
| Grade | Standard | Anti-Static | Anti-static(Optical) |
| Colour | Blue | Black | Grey |
| Density(g/mm3) | 1.85 | 1.85 | 1.85 |
| Standard OperationTemperature | 260 | 260 | 260 |
| Maximum Operation Temperature(C) | 350 | 350 | 350 |
| Sheet Size(mm) | 2440×1220 | 2440×1220 | 2440×1220 |
| Tickness/weight(mm/kg) | 3/17, 4/22 | 5/28, 6/33, 8/44 | 10/55, 12/66 |
Our goal is to design and build a solution that will give you:
1. Highest yields with the largest process window possible.
2. Easy to use tooling that will survive your manufacturing environment.
3. Fastest delivery times possible.
