manual pcb depaneling machine with 720mm length blades
USD $1 - $2,500
/ Set
1 Set(Min.Order)
- 360 Set / Sets per Month
- shenzhen/hongkong
- Credit Card
You May Like
Product Details
| Condition: | New | Laser Type: | Other, manual | Applicable Material: | Crytal, Glass, MDF, Metal, plastic |
| Cutting Thickness: | 0.8-3.5mm | Cutting Area: | 460/700mm | Cutting Speed: | 100-500mm/s |
| CNC or Not: | No | Cooling Mode: | Air Cooling | Control Software: | manual |
| Graphic Format Supported: | BMP, DWG, DXF | Place of Origin: | Guangdong, China | Brand Name: | Chuangwei pcbdepaneling machine |
| Model Number: | CWV-1M | Certification: | CE, SGS | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Manual pcb depaneling machine with 720mm length blades ,Manual type PCB separator separation 700mm length pcb
pcb depaneling machine spec:
| Model number | CWV-1M |
| PCB cutting length (mm) | 460/700/1000/1500 |
| Cutting speed (mm/s) | 100/200/300/500 |
| Cutting thickness(mm) | 0.6-3.5 |
| Power supply (v) | manual control |
| Size | 400*780*480 |
| Weight(kg) | 30/50/60/80 |
Features for pcb depaneling machine :
Manual Circular & Linear Blade Depanelizer CWV-1M
- Round knife, manually cutting against lower linear knife, for reduced stress
- Separate pre-scored PCB assembly without stress on either PCB or component
- One touch programming of cut length with digital display
- Separating speed is adjusted by a rotary knob
- Handle Intermittent scoring or cut-outs
- Board with projected component can be cut precisely
- Large stainless steel platform on both side of cutting blade prevents board wobble and table height and angle are adjustable
- Optional PCB conveyor belt to remove finished board
- Clearance between circular and linear blades are adjustable to fit different groove depth and compensates for blade wear out.
Detailed pcb depaneling machine pictures :
Regular customers for pcb depaneling machine :
Company information :
Certificate :
Contact Us
- Dongguan Chuangwei Electronic Equipment Manufactory
- Contact nameAlan Cao
- Phone86-769-89990229
- AddressNo.8 Kangxiang East Street,Yongtou Village,Changan Town,Dongguan City,Guangdong Province ,China Dongguan,Guangdong
