Specifications
Concrete sand sifter:1.ISO 9001:2008
2.Long using 6 months warranty
3.High siffting ratio >95%
Working Principle:
These series circular vibratory sieve applies vibrating electrical motor, through the shaking of the screen can increase the efficiency of separating. We set layers on the screen with various types, so you can convey the big material to the crusher once again by the conveyor for the second crushing
Advantage:
It has many advantages compared to the traditional screen:
1. The shaking motor can increase the efficiency of sifting
2. We use the superior steel to make these vibratory sieve ,to guarantee the quality and durable function.
3. It has simple structure , so it is easy to maintain and the main part is durable to use.
4. The up vibrating types apply shaking box structure , so it easy to control the force.
5. We offer our products on the base of our test results, so we can supply superior function products.
Vibratory sieve parameters:
Type |
Net layers |
Net area (m2) |
Vibrating Frequency (r/min) |
Double amplitude (mm) |
Power (KW) |
Capacity(t/h) |
Theoretical weight(t) |
YK1860 |
1 |
10.8 |
960 |
5 -8 |
7.5 |
120-240 |
2.4 |
YK2060 |
1 |
12 |
7.5 |
150-260 |
2.6 |
||
YK2260 |
1 |
13.2 |
7.5 |
180-280 |
3 |
||
YK2460 |
1 |
14.4 |
7.5 |
210-300 |
3.3 |
||
2YK1560 |
2 |
8 |
7.5 |
80-200 |
3.5 |
||
2YK1860 |
2 |
10.8 |
11 |
120-240 |
4 |
||
2YK2060 |
2 |
12 |
11 |
150-260 |
4.1 |
||
2YK2260 |
2 |
13.2 |
11 |
180-280 |
4.4 |
||
2YK2460 |
2 |
14.4 |
11 |
210-300 |
4.7 |
||
3YK1560 |
3 |
8 |
15 |
80-200 |
4.8 |
||
3YK1860 |
3 |
10.8 |
15 |
120-240 |
5 |
||
3YK2060 |
3 |
12 |
15 |
150-260 |
5.1 |
||
3YK2260 |
3 |
13.2 |
15 |
180-280 |
5.2 |
||
3YK2460 |
3 |
14.4 |
15 |
210-300 |
5.3 |
||
4YK1860 |
4 |
10.8 |
18.5 |
120-240 |
5.7 |
||
4YK2060 |
4 |
12 |
18.5 |
150-260 |
5.8 |
||
4YK2260 |
4 |
13.2 |
18.5 |
180-280 |
6 |
||
4YK2460 |
4 |
14.4 |
22 |
210-300 |
6.2 |
||
5YK1560 |
5 |
8 |
15 |
80-200 |
5.2 |
||
5YK1860 |
5 |
10.8 |
15 |
120-240 |
5.4 |
||
5YK2060 |
5 |
12 |
15 |
150-260 |
5.6 |
