Specifications
Screening equipment advantage1.High screening efficiency
2.Certification ISO9001:2008
3.Steady struction
4.Easy maintenance
Screening equipment Features:
1 high efficiency, compact design and durability, any powder and sand can be screening.
2 changer is easy, simple, easy to clean.
3.unique grid design, screen used for a long time for network speed, screen up to 7 layers.
4. impurities, coarse material discharged automatically, you can continuous work.
5. low energy consumption, maintenance is simple, without foundation installation.
Screening equipment Application:
The product is applicable to any powder, granule, and filtering of the industry. YK series rotary vibration screen is widely used in chemical industry, medicine powder, liquid, paint, pigments, cosmetics, oil, resin, ceramic slurry, clay slurry, lime, refractory powder at the end, magnetic powder, polishing powder, fruit juice, beverage, sugar, salt, MSG, spices, milk powder, starch, flour, rice flour, carbon powder, graphite powder, manganese powder, lithium carbonate, help solvents, fire extinguishing agents, as well as the environmental protection industry wastewater, wastewater treatment process of screening, filtering.
The main parameters:
Type |
Net layers |
Net area (m2) |
Vibrating Frequency (r/min) |
Double amplitude (mm) |
Power (KW) |
Capacity(t/h) |
Theoretical weight(t) |
YK1860 |
1 |
10.8 |
960 |
5 -8 |
7.5 |
120-240 |
2.4 |
YK2060 |
1 |
12 |
7.5 |
150-260 |
2.6 |
||
YK2260 |
1 |
13.2 |
7.5 |
180-280 |
3 |
||
YK2460 |
1 |
14.4 |
7.5 |
210-300 |
3.3 |
||
2YK1560 |
2 |
8 |
7.5 |
80-200 |
3.5 |
||
2YK1860 |
2 |
10.8 |
11 |
120-240 |
4 |
||
2YK2060 |
2 |
12 |
11 |
150-260 |
4.1 |
||
2YK2260 |
2 |
13.2 |
11 |
180-280 |
4.4 |
||
2YK2460 |
2 |
14.4 |
11 |
210-300 |
4.7 |
||
3YK1560 |
3 |
8 |
15 |
80-200 |
4.8 |
||
3YK1860 |
3 |
10.8 |
15 |
120-240 |
5 |
||
3YK2060 |
3 |
12 |
15 |
150-260 |
5.1 |
||
3YK2260 |
3 |
13.2 |
15 |
180-280 |
5.2 |
||
3YK2460 |
3 |
14.4 |
15 |
210-300 |
5.3 |
||
4YK1860 |
4 |
10.8 |
18.5 |
120-240 |
5.7 |
||
4YK2060 |
4 |
12 |
18.5 |
150-260 |
5.8 |
||
4YK2260 |
4 |
13.2 |
18.5 |
180-280 |
6 |
||
4YK2460 |
4 |
14.4 |
22 |
210-300 |
6.2 |
||
5YK1560 |
5 |
8 |
15 |
80-200 |
5.2 |
||
5YK1860 |
5 |
10.8 |
15 |
120-240 |
5.4 |
||
5YK2060 |
5 |
12 |
15 |
150-260 |
5.6 |
