Hight Precision Soldering Machine Soldering FPC To PCB Board

Hight Precision Soldering Machine Soldering FPC To PCB Board thumbnail-1
Hight Precision Soldering Machine Soldering FPC To PCB Board thumbnail-2
Hight Precision Soldering Machine Soldering FPC To PCB Board thumbnail-3
Hight Precision Soldering Machine Soldering FPC To PCB Board photo-1
Hight Precision Soldering Machine Soldering FPC To PCB Board photo-2
Hight Precision Soldering Machine Soldering FPC To PCB Board photo-3
US$ 1 - 2 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Chuangwei Hight Precision soldering machine
Model Number:
CWPC-1A Hight Precision soldering machine
Contact Supplier Request Quote Chat Now
Dongguan Chuangwei Electronic Equipment Manufactory
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/hongkong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Chuangwei Hight Precision soldering machine
Model Number CWPC-1A Hight Precision soldering machine
Voltage 110/220
Current OPTIONS
Rated Capacity option
Rated Duty Cycle option
Dimensions 620*690*570MM
Weight 95KG
Usage welding fpc, ffc and pcb
Certification CE ISO
After-sales Service Provided Engineers available to service machinery overseas

Hight Precision soldering machine Soldering FPC To PCB Board



Specification for soldering machine :



working area 200*260mmm
Temperature setting +-2
Depression 0.45-0.7 Pa
Fixture 1 set
Size 620*690*570mm
Weight 95KG
Temperature setting 20~500
Temperature precision +-2
Bonding times 1-99 s
Precision 0.05





Features for soldering machine :



Pulse-Heated Soldering Machine with Pneumatic Rotary Turntable  CWPC-1A
1.Extremely short cycle time with rotary table design. Product loading and  unloading can be done during the heat sealing process
2.High quality heat seal application up to 0.25mm pitch
3.Pneumatic bonding head provide up to 3,900N force
4.Digital programmable pressure control with LCD display
5.Closed loop PID temperature control with visible LED display
6.Bonding cycle is triggered by a real time pressure sensor
7.Floating Thermode ensure consistent pressure and heat transfer along the flexfoil to LCD and/or PCB
8.Precision product fixtures (2X), easy exchange, provided with micrometer alignment and vacuum to fix components
9.Optional CCD alignment module with frame, camera, lens, monitor and illumination for fine pitch application
10.Full microprocessor logic control



Hight Precision soldering machine Soldering FPC To PCB BoardHight Precision soldering machine Soldering FPC To PCB BoardHight Precision soldering machine Soldering FPC To PCB Board
