Specifications
Electrical plug,small connector have the features of small size,light weight,convenient application with threaded-coupling.Electrical plug,aviation plug,small connector have the features of small size,light weight,convenient application with threaded-coupling connection.It can be interchanged with Russian type PC, They are widely used for the electrical connection between electrical equipments and instruments. Product Ordering
PC -- 4 Z
1 2 3
1.Name PC series connectors
2.Number of contacts 4,7,10,19,32,50
3. T-plug,Z-receptacle,P-Cable shell,ZP- cable receptacle
Technical characteristics
Temperature |
Relative humidity |
Atmosphere |
Vibration |
Shock |
Endurance |
|
-40°C~ +105°C |
(92~98)%, at40+2°C |
101.33KPa~6.67Pa |
10~2000Hz, 196m/s² |
392m/s² |
500 cycles |
Current |
Voltage |
Contact resistance |
Contact Ø |
3A |
200V |
≤8mΩ |
Ø1mm |
Environment |
Voltage proof |
Insulation resistance |
Normal |
1000V |
≥1000MΩ |
High temperature |
700V |
≥500MΩ |
Moisture |
500V |
≥50MΩ |
Low pressure |
200V |
- |
