Made in China retreading equipment factory
Why choose tire retreading business?
1 Market high need
2 High profile but low cost
3 Goverment support
4 Environmental
More and more people see the high profile which tire retreading bring,so now,there is a lot of small factory to engaged in this area,but if you want to get the good tire,you must choose good tire retreaing equipments.
our company are mainly produing tire retreading equipments,and the products have exported to all over the world.now ,we have professional engineer to design,1000 square factory to produce and store our products.
if you want to learn more about our machine,welcome to visit our factory.
Tire retreading process:
Waste tire-inspect -washing and dry-Grind tire-Tire repair-Rubberized-Tread and considerate cooperation-Autoclavel
Main equipments of High profile business tyre retreading for truck and car
1 Autoclavel
Tyre autoclaveis mainly to heat and through air presser to press tyre body and level.
This equipments have strict requirement on safety and quality,however,our machine is trough testing of safety and quality,so it is good product.
Heat way:electricity,oil heat ,or steam heat
Power:30kw-90kw
Specification:
Diameter of autoclave |
Tyre number |
1.5*1.5m |
4 |
1.5*2m |
6 |
1.5*2.5m |
8 |
1.5*3m |
10 |
1.5*4m |
12 |
1.5*5m |
16 |
2 Tyre circle round frame
Function:which is mainly to transport tyre before autoclave and after autoclave,the biggest load weight can up to 300kg.
3 Tire grinding machine
Function: (1) for a tire polishing the rough surface of the arc;
(2)equipped with tire inflation riot function
1 Specifications: 15 ", 16", 20 ", 22.5"
2 Dimension: 1.6 × 1.8 × 2.1 m
3 Weight: 1550 kg
4 the technical parameters:
(a) grinding motor power: 11kw
(b) tire Nominal power: 2.2kw;
(c) grinding so equipped with power: 0.55kw;
(d) before and after grinding head equipped with power: 0.37kw.
4 Tread laminating machine
Function: for tread and carcass laminated with tire explosion-proof function
1 Application Size: 15 ", 16", 20 ", 22.5"
2 Dimension of Tread laminating machine : 1.8 × 2.1 × 2.1 m
3 weight: 850 k5,
4 the technical parameters:
(1) the pressure roller equipped with power: 0.55kw
(2) pressure roller equipped with power: 0.37kw
5 Envelopes changer
Function: for tire curing envelopes before and after disassembly, for a variety of tires
1 Size: 15 ", 16", 20 ", 22.5"
2 Dimension: 2.2 × 1.5 × 1.6 m
3 weight: 350 kg
In addition to these mainly machine,there is also some assist equipment :
Stirred pulp,wheel changer,tape extruder,tire repair and rubberized shelf and powder collector tank.
Benefits of tyre retreading
The benefits of retreading are both environmentally friendly and cost-efficient! When the tread has worn off, only about 20% of the tyre is used up. The carcass, which represents about 80% of the tyre's value, can be re-rubberized for a "new tyre life".
To produce a truck or bus tyre requires about 60-80 kg of rubber mixture. Retreading the tyre takes only about 15 kg of rubber. A considerable amount of raw materials can therefore be saved. In the EU, this equates to more than 300,000 tones per year!
To produce a car tyre requires about 28 litres of crude oil. To retread a car tyre, on the other hand, only 5.5 litres of oil are needed
optional type size
650-1200 (14″,15″,16”,17.5”,20″,22.5”)
6.50-16", 7.00-22.5", 22.5-16", 7.50-16", 8.25-16"
9.00-20", 10.00-20", 11.00-20", 12.00-20",
11.00R22.5", 12.00R22.5", 295/80R22.5, 315/80R22.5
28X9-15", 6.50-10, 12.00-24", 14.00-24, etc .
Optional producing line of Made in China retreading equipment factory
4pcs production line, 6pcs production line
8pcs production line, 10pcs production line
12pcs production line, 16pcs production line
20pcs production line, 24pcs production line, etc
Made in China retreading equipment factory
