Specifications
hot sales!wireless pstn laser security alarm system with panic button2.three years warranty
hot sales!wireless pstn laser security alarm system with panic button
1.TFT color screen with english menu
2.4 wired and 99 wireless defense zone
. Features
| Model NO.: | YL-007TF |
|---|---|
| Working Principle: | Electronic Security Equipment |
| Application: | home security |
| Sensor Type: | Electric Alarm |
| Working Mode: | Active |
| Signal Transmission: | Wireless Alarm |
| Type: | Anti-Theft Alarm |
| Usage: | Auto |
| Export Markets: | Global |
Additional Info.
| Trademark: | Wolf Guard |
|---|---|
| Packing: | Gift Box |
| Standard: | 118*84*29mm |
| Origin: | Shen Zhen/China |
| Production Capacity: | 98000PCS/Month |
Product Description
Host size: 170*112*30mm
Gift box size: 320*263*63mm G. W.: 984G
[Function Instruction]
- TFTColor Screen with English menu and voice prompt, simple operation.
- 99 defense zones, each zone has 8 defense types available for choice: common defense zone, stay defense zone, intelligent defense zone, emergency defense zone, close defense zone, Chime defense zone, welcome defense zone, help senior defense zone. Each defense zone can arm/ disarm independently.
- Four groups of timing arm/ disarm function; each timing can be set in different zones.
- Alarm call is prior to normal call even when the phone is busy.
- 10 seconds automatic message recording. With built-in human voice prompt, users will know the alarm position and defense zone No. when remotely receiving the alarm.
- Remote listening in different places and remotely arm and disarm by phone.
- Simple and fast to add wireless accessories. Alarm panel is compatible with 2262 coding format and millions of code and can add up to 150 remote controllers and 150 detectors.
- Adopt High Precision Clock IC to ensure that the previous time will not lose when power is off.
- Black Box function: Alarm panel automatically records 72 pieces of arm, disarm and 102 pieces of recent alarm events.
- Compatible with internationally accepted protocol of alarm receiving center: Ademco Contact ID alarm communication protocol. (this function is optional. Please contact us if needed.)
Technical Parameters
Power Supply: DC9V-12V(Built-in rechargeable battery)
Static Current: <20mA
Alarm Current: <450mA
Wireless frequency: 433MHz±0.5MHz
PT2262/1.5-4.7M, EV1527/300K
Wireless receiving flexibility: 5mV/m
Wireless Alarm Siren: 110db
Working Temperature: 0°C~+40°C
Humidity: ≤90% (no fog)
Wireless detector: maximum 150pcs
SUITABLE OCCASIONS:
Villa, home, house, residential, shop, school, bank, small&middle supermarket, company, the factory floor, garage, financial room, finacial sales, machine room, base station, important unattended monitored place intrusion and remote control alarm
Basic Kit contains:
- Alarm host (control unit) * 1 PC.
- Wireless PIR detector * 1 PC.
- Wireless door (gap) sensor * 1 PC.
- Remote controller * 2 PCS.
- Antenna * 1PC.
- Mini wired siren 110dB/0.3m * 1 PC.
- Power adapter * 1PC.
- User manual * 1PC.
