86-15836573007 different sizes rhinestones hot fix rhinestone machine
Biggest advantage compared with hot fix rhinestone machine
1) Saving labours: one machine can instead of 3 workers at least.
2) Rhinestons is not easy to fall off after being cleaned by water.
3) Can fix thinestones more accurately and makes the goods more attractive.
Working theory of rhinestone machine
Through unltrasonic heating principle, picking up rhinestones by Pneumatic control method. At the smae time move the material accordingly by hand after the red light locate, then the machine will fix rhinestones on the material quickly. Working speed can reach 220-260pcs rhinestones per minute, and will not fall off after being cleaned by water.
Characters
1)Adopting ultrasound, this machine is able to hot fix the rhinestone in purpose materials immediately, such as Denim,Cotton,Jeans,Hemp fabric,Woolen,Synthetic Fiber,Silk,Knitwear,Synthetic Leather,Velvet etc. Especially suitable for the material that can't resist high temperature and easy to deform and discolor.
2) Main components specially imported from other countries, such as two five-way solenoid valve uses from south Korean, cylinder adopts Germany FESTO, two two-way adopt Japan CKD, assuring superior quality and reliable usage.
3) Infrared positioning, precisely hot fix the rhinestone's position and very strong sticking effect
4) Five different size of suction nozzle: 10# 12# 16# 20# 30#
5) Able to work continuously 24 hours, high working efficiency.
Application of hot fix rhinestone machine
Manily used for women's clothes, underwear, children's wear, T-shirt, embroidery patterns, belts, handbags, hats and supplemental supplies, etc
Three models hot fix rhinestone machine
1) ALC8-TZA: Single Disc and single welding head: only can fix one kind of rhinestone one time.
2) ALC8-TZB: Double discs and single welding head: can fix two kinds of rhinestones at same size one time.
3) ALC8-TZC: Double discs and double welding heads: can fix two kinds of rhinestones at two sizes one time.
Technical parameter
Model |
ALC8-TZA |
ALC8-TZB |
ALC8-TZC |
Working speed |
220-260pcs/min |
220-260pcs/min |
220-260pcs/min |
Voltage |
220v/50hz/1phase |
220v/50hz/1phase |
220v/50hz/1phase |
Power |
0.3kw |
0.3kw |
0.3kw |
Air Pressure |
0.4-0.5MPA |
0.4-0.5MPA |
0.4-0.5MPA |
Welding head |
1 pc |
1 pc |
2 pcs |
Disc |
Single disc |
Double Discs |
Double Discs |
Working table size |
800*650mm |
800*650mm |
800*650mm |
Size of rhinestone |
10# 12# 16# 20# 30# |
10# 12# 16# 20# 30# |
10# 12# 16# 20# 30# |
Besides dear we also have manual rhinestone machine
Pls let me know if there is any question about our hot fix rhinestone machine, looking forward to your enquiry
