304l Stainless Steel Angle Bar
US$ 800.00 - 800.00
MOQ: 1 Ton
Key Specifications
Get Latest Price
Standard:
AISI, ASTM
Dimensions:
20*20*2mm)-(200*200*25mm)
Grade:
A36-A992 Series
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Aisi 304lstainless Steel PlateUS$ 2000.00 - 2000.00MOQ: 1 Ton -
304 Stainless Steel HoseUS$ 2.25 - 25.52MOQ: 200 Meters
-
304 Stainless Steel BellowsUS$ 1 - 15MOQ: 100 Pieces
-
Gold Supplier 304 Stainless Steel HoseUS$ 2.25 - 25.52MOQ: 200 Meters
-
Prime Quality 304 Stainless Steel HoseUS$ 2.25 - 25.52MOQ: 200 Meters
Standard
AISI, ASTM
Dimensions
20*20*2mm)-(200*200*25mm)
Grade
A36-A992 Series
Place of Origin
Jiangsu, China
Brand Name
jirunxing
Model Number
Q195
Type
Equal
Application
Bridge
Product Description
Products(free samples are avaiable)
1) Grade: 200 series, 300 series, 400 series
2) Standard: AISI, ASTM, DIN, GB, JIS, SUS
3) Specification:2.5#---20#
4) Length: 6 meters or as required
5)Technique: Hot rolled/annealed/pickled
6) Certification: ISO9001: 2008 / SGS
7) Application: widely used in chemical, shipping, architecture, machine-made, household products industry, etc.
8) Delivery: Within 30 days upon receipt of 30% deposit
9) Payment: T/T or L/C at sight
10) Trade Terms: FOB/CIF/C&F
Theoretical Weight Calculation Formula of 304L Stainless Steel Angle Bar 0.00793 Χ(Siding A + Siding B - Thickness)Χ Thickness (Unit: KG/Meter)
Chemical Elements of 304L Stainless Steel Angle Bar
| Material | C %(≤) | Mn % (≤) | P % (≤) | S % (≤) | Si % (≤) | Cr% (≤) | Ni% (≤) | Mo% |
| 304L | 0.03 | 2 | 0.045 | 0.03 | 1 | 18.00-20.00 | 8.0-10.50 | - |
Tolerance of Different Grades of 304L Stainless Steel Angle Bar
| Grade | Specification | Side Allowble Deviation | Thickness | |||||||||
| 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | |||
| Tickness Allowble Deviation | ||||||||||||
| 2.5# | 25×25 | ±1.5 | ±0.5 | ±0.5 | ±0.5 | / | / | / | / | / | / | / |
| 3# | 30×30 | ±2.0 | ±0.5 | ±0.5 | ±0.5 | ±0.5 | / | / | / | / | / | / |
| 4# | 40×40 | ±2.0 | ±0.6 | ±0.6 | ±0.6 | ±0.6 | ±0.6 | / | / | / | / | / |
| 5# | 50×50 | ±2.0 | ±0.6 | ±0.6 | ±0.6 | ±0.6 | ±0.6 | / | / | / | / | / |
| 6# | 60×60 | ±3.0 | / | ±0.6 | ±0.6 | ±0.6 | ±0.6 | ±0.6 | / | / | / | / |
| 6.5# | 65×65 | ±3.0 | / | / | ±0.6 | ±0.6 | ±0.7 | ±0.7 | ±0.7 | / | / | / |
| 7# | 70×70 | ±3.0 | / | / | ±0.7 | ±0.7 | ±0.7 | ±0.7 | ±0.7 | ±0.7 | / | / |
| 7.5# | 75×75 | ±3.0 | / | / | / | ±0.7 | ±0.7 | ±0.7 | ±0.7 | ±0.7 | / | / |
| 8# | 80×80 | ±3.0 | / | / | / | ±0.7 | ±0.7 | ±0.7 | ±0.7 | ±0.7 | / | / |
| 9# | 90×90 | ±3.0 | / | / | / | / | ±0.7 | ±0.7 | ±0.7 | ±0.8 | ±0.8 | ±0.8 |
| 10# | 100×100 | ±4.0 | / | / | / | / | ±0.7 | ±0.7 | ±0.7 | ±0.8 | ±0.8 | ±0.8 |
Packaging & Shipping
| Packaging Details: | 304L Stainless Steel Angle Bar: Woven bag, coil, others are also available according to client' requirement |
| Delivery Detail: | 15 days upon receipt of the 30% deposit |
