Specifications
304 Stainless steel angle bar1.Certificate:ISO
2.High quality, best price
3.Manufacture supply directly
4.OEM Service
304 Stainless steel angle bar
Product advantage
1.Certificate:ISO
2.High quality,best price
3.Manufacture supply directly
4.OEM Service
Product Instruction
1.Size : 2.5 #, 3 #, 4 #, 5 #, 6 #, 6.3 #, 6.5 #, 7 #, 7.5 #, 8 #, 9 #, 10 # etc
2.Lenght : 2-8 meters depend on requirement
3.Material : 200 series,300series, 400series
Grade : 201 /430/410/ 304 /304L/316/316L /310s /904 / 904L / 316Ti /321 etc .
4.Surface: HRAP , hot rolled pickled , polished , sand blasting
5.Standard: JIS, AISI, ASTM, GB, EN
Size of stainless steel angle (mm)
25×25×(3,4,5) | 30×30×(3,4,5) | 40×40×(3,4,5,6) | 40×40x(3,4,5,6) |
60×60×(4,5,6,8) | 63×63×(4,5,6,8) | 65×65×(4,5,6,8) |
70×70×(5,6,8,10) |
75×75×(5,6,8,10) | 80×80×(5,6,8,10) | 100×100×(8,10,12) |
Composition ranges for 304 grade stainless steel
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
304 | min. max. | - 0.08 | - 2.0 | - 0.75 | - 0.045 | - 0.030 | 18.0 20.0 | - | 8.0 10.5 | - 0.10 |
304L | min. max. | - 0.030 | - 2.0 | - 0.75 | - 0.045 | - 0.030 | 18.0 20.0 | - | 8.0 12.0 | - 0.10 |
304H | min. max. | 0.04 0.10 | - 2.0 | - 0.75 | -0.045 | - 0.030 | 18.0 20.0 | - | 8.0 10.5 | - |
Product image
Certificate
Company profile
TIANJIN TEDA YADA STEEL CO., LTD steel with twenty years of experience deal with stainless steel products,
include stainless steel sheet, stainless steel pipe, stainless steel coil,stainless steel bar and so on. YADA
steel is a highly professional manufacturer and at the same time we have good relation with big steel factory
in china.
We have 37,000 square meters of factory building area with about USD 350,000,000 fixed assets, 2,00
employees and USD300, 000,000 annual sales. At present, our production capacity is about 50,000 ton
per year.
Company Name:TIANJIN TEDA YADA STEEL CO., LTD
Address:NO.398, Nankai District,Tianjin City, China
Website:
Contact person:Ms Helen
Mob:0086-15822006452
Ph:0086-22-27365018
Fax:0086-22-27646194
Postcode:300110
