Satellite Universal Single best lnb

Item

Specification

Item

Specification

Input Frequency Range

Low Band:10.70~11.70GHz
High Band:11.70~12.75GHz

L.O. Phase Noise

-50dBc/Hz@1KHz
-75dBc/Hz@10KHz
-95dBc/Hz@100KHz

Output Frequency Range

Low Band:950~1950MHz
High Band:1100~2150MHz

Image Rejection

40dB(Min.)

Noise Figure

Low Band:0.6dB(Typ.)
High Band:0.6dB(Typ.)

Output VSWR

2.0:1(Max.)

Conversion Gain

60dB(Typ.)

Output Power

0dBm (Min.)(at 1dB gain
compression)

Gain Flatness

±0.5dB/26MHz

Connector Type

75Ω Female Connector

Cross POL. Isolation

25dB(Typ.)

DC Current Consumption

80mA(Typ.)

L.O. Frequency

Low Band:9.75GHz
High Band:10.60GHz

Low/High Band Switching

Low Band:0Hz
High Band:22KHz±4KHz

L.O. Frequency Stability

±1.0MHz (Max.)@+25°C
±2.0 MHz (Max.)@-30°C~+70°C

POL. Switching Voltage

10.5~14.0V @VP
16.0~20.0V @HP

 Operating Temperature

 -30°C~+70°C
