Specifications
1)Steam sterilization testing machine2) Used to sterilization by high temperature
3) Suitable for packing trade, film bags
Steam sterilization testing machine
Function and usage:
1) It is applicable for the packaging trade, film plant, food plant, testing institution,
scientific and research institute, and medical unit and so on;
2) It is used to sterilize the packaging materials (as well as adhesive and printing ink)
with high temperature boiling resistance;
3) It is used to judge the high temperature resistant properties of packing material by boiling.
Technical Parameter :
The diameter of sterilizing barrel | φ400mm;H500mm |
The capacity of storage barrel | 50L |
Range of working pressure | 0~0.22Mpa (saturated vapor pressure) |
Power consumption | 4.5kw±10% |
Water compensation pressure | ≥0.32 Mpa |
Sterilization temperature | 100~135°C |
Inverted pressure | 0.14~0.165 Mpa |
Dimension | 560(L)mm×500(W)mm×1150(H)mm |
Weight | 80kg |
Operational power supply | AC220V /50Hz |
