Heating Seal Tester (GBB-F)
- Guangzhou
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | GBPI | |
| Model Number | GBB-F | Power | Electronic | |
| Usage | Plastic Testing Machine |
Product Description
GBB-F Heating Seal Tester
Heating Seal Tester
Standards:
ASTM F 2029-2000, QB/T 2358-1998, ,YBB 00122003
Function:
To test package heating tempeature range, heating seal strength , heat sealing speed and pressure tec.
Application:
* Films
rigid films, shrik films, stretch films, plastic films, plastic composite films, paper-plastic composite films,aluminized films, aluminum foil, aluminum composite films, high barrier films and many others. Eg. PET, OPP, CPP, LDPE, BOPP
* Sheet
engineering plastics, rubber, waterproof building materials, and thermal insulation materials, e.g. PP, PVC, PVDC, and nylon
*Packages
paper, plastics, rubber, paper, paper-plastic composite, glass, and metal packages, eg: bottles and containers.
Techinical Parameter
Heat sealing temperature | room temperature ~ 300℃ |
Temperature accuracy | ±0.1℃ |
Heat sealing time | 0.01s~99.99h |
Heat sealing pressure | 0.05~0.8Mpa |
Heat sealing area | 45×10mm x 5 points, smooth, lower blade with silicon pad, can customize size |
Heating mode | automatic or manual |
Instrument size | 700×400×540mm |
Power supply | 220V, 50Hz |
Features:
1.Dual-temperature, dual control, dual display;
2.An external cylinder,printer inside, use friendly;
3.Superior components imported brands configurations;
4.Elegant appearance, accurate test data;
5.Excellent performance of the start sealing temperature, sealing speed, heat sealing strength;
6.Versatile languages support.
After sale Service:
1. One year guarantee and all lifetime techinical support
2. USA, Australia Aisa Local agent for service
3. Speedy reply, 12hrs response to customer questions
4. Software free update
5. Minor maintenance ---parts ship within 24 hrs
6. Major maintenance---Technical will be sent within 15 days
