Help CenterBlister Package Electronic Tensile Tester (ASTM D882)
Related Products
Specifications
1.GBH Electronic tensile testing machine2.is for test of tensile,compression,flexure,shear,peel and so on on film,materials.
GBH tensile tester for blister package (ASTM D882)
Function and usage:
GBH Electronic Tensile testing equipment is applicable for the test and analysis of mechanical properties, such as peeling, tension, splitting, puncture and so on for composite material, packaging material, adhesive tape. The tensile strength, yield strength, coefficient of extension, fixed elongation stress and elongation parameter under fixed stress can be calculated out automatically according to some standards, such as GB, JIS, ASTM, DIN and so on.
Technical specification:
Force measurement range |
0~500N (0-5000N is optional) |
Force measurement precision |
Within ±0.5% of the indicating value. |
Force measurement resolution |
1/50,000 of the sensor’s full range |
Test speed |
0~500mm/min (stepless speed changing) |
Displacement precision |
Within ±1% of the indicating value |
Test stroke |
800 mm |
Power |
AC220V /50Hz |
Dimension |
480(L)mm×450(W)mm×1050(H) mm |
Weight |
75kg |
For more information,pls contact Janice:86-13611409721
