Specifications
Tensile tester is lab testing equipmentReliable to test tensile, stripping,puncture,compression,sealing,bending,shearing
Function and Usage:
GBH-1 universal single-pole electronic tensile machine is suitable for tensile, stripping, sealing, tear, puncture, compression, bending, shearing these kind of mechanical properties testing of all kinds of plastic film, paper-plastic composite film, tape, soft packaging material, a rubber sheet, paper, non-woven fabricsetc.
High precision, easy to operate, intuitive and reliability.Comply with the requirements on testing technical of National technical supervision departments. It has been widely used in product quality control in plastic film, food, pharmaceutical industries and research & teaching experiments in testing institutions.
Standards:
ASTM D828,ASTM E4,ASTM D882,ASTM D1938,ASTM D3330,ASTM F88,ASTM F904,ISO 37
Application :
* Films
rigid films, shrik films, stretch films, plastic films, plastic composite films, paper-plastic composite films,aluminized films, aluminum foil, aluminum composite films, high barrier films and many others. Eg. PET, OPP, CPP, LDPE, BOPP
* Sheet
engineering plastics, rubber, waterproof building materials, and thermal insulation materials, e.g. PP, PVC, PVDC, and nylon
*Packages
paper, plastics, rubber, paper, paper-plastic composite, glass, and metal packages, eg: bottles, containers,
Features:
1. Accurate test data, simple layout, use friendly;
2. Versatile test functions such as tensile, flexure, puncture, sealing, peeling etc
3. Measurement force range 0-500N is best value for flexible packaging materials test;
4. Automation save and print test reports;
5. Connecting computer to operate or without computer to test separately.
6. LCD screen on real time display, easily modify parameters;
7. adopts superior components;
8. Versatile operation languages support.
Specification
Force measurement range: 0-500N(0~3000N is optional )
Force measurement resolution: within ±0.5% of the indicating value (0.5 grade )
Test speed: 0-500mm/min (stepless speed regulation)
Displacement precision: Within ±0.5% of the indicating value.
Effective test width : 30mm
Effective test travel: 800mm
Elongation rate : 1500%
Dimension: 600(L)mm×600(W)mm×1300(H)mm
Power : 1000W
Weight: 70kg
Service
1: One year guarantee and all lifetime techinical support
2: USA, Australia Aisa Local agent for service
3 Speedy reply, 12hrs response to customer questions
4 Software free update
5. Minor maintenance ---parts ship within 24 hrs
6 Major maintenance---Technical will be sent within 15 days
Certificate:
Our customer:
Our Laboratory:
Our team:
