Street Highway,square,garden,residential Light Poles,industrial Light Poles

Name: Street Highway,square,garden,residential Light Poles,industrial Light Poles
Brand: yinhe
SKU: 102392369
Availability: InStock

Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Brand Name:

yinhe

Model Number:

MW-002

Jiangsu Milky Way Steel Poles Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Brand Name yinhe

Model Number MW-002

Material Other, Steel, Steel

Type Polygonal

Application Other

Street highway,square,garden,residential light poles

Height	From 6 m to 15 m
Suit for	Airport ,seaport,plaza,stadium ,square,highway,street way etc
Shape	Conoid ,Multi-pyramidal,Columniform,polygonal or conical
Material	Q235B/A36,minimum yield strength>=235 Mpa
Lamp power	20 W- 400 W (HPS/MH) 220V (+-10%) /50Hz
Torlance of the dimenstion	+- 2%
Optical assembly of lighting fixture	IP 65
Electroshock resistant protective grade	Grade Ⅰ
The casing anti-corrosion performance	Class Ⅱ
Working atmosphere of lighting fixture	-35 °C~+45 °C
Surface treatment	Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.
Joint of Poles	Insert mode,innerflange mode,face to face joint mode
Design of pole	Against earthquake of 8 grade
Wind Speed	160 Km/Hour
Minimum yield strength	235 mpa
Minimum ultimate tensile strength	350 mpa
Max ultimate tensile strength	620 mpa
Standard	ISO 9001
Length of per section	Within 14m once forming without slip joint.
Welding	We has past flaw testing.Internal and external double welding makes the welding beautiful in shape Welding Standard :AWS (American Welding Society ) D 1.1
Thickness	4mm
Production Process	Rew material test → Cuttingj →Molding or bending →Welidng (longitudinal )→Dimension verify →Flange welding →Hole drilling →Calibration → Deburr→Galvanization or powder coating ,painting →Recalibration →Thread →Packages
