2016 Popular Cheap Custom Logo Brass Gas Ball Valve
Product Name |
Brass Gas Ball Valve |
| Valve body: | Forged brass |
| Valve seat: | Brass |
| Valve stem: | Chrome-plated brass |
| Actuator shell: | Aluminum |
| Actuator bottom case: | Stainless steel |
| Working voltage: | 24VAC, 110/120VAC, 230VAC; 50/60Hz |
| On/off time: | 13-18s |
| Spring return time: | 4-5s |
| Motor power: | 6.5W, 7 VA |
OEM & ODM |
Acceptable |
| Thread Type | BSP NPT |
Model No. |
Size |
Description |
Kv(Cv) |
Closing pressure |
Weight (g) |
SW-B152 |
15MM (1/2’’) |
2 way valve |
2.2(2.5) |
0.18MPa (25PSI) |
700 |
SW-B202 |
20MM (3/4’’) |
3.0(3.5) |
0.16MPa (23PSI) |
850 |
|
SW-B252 |
25MM (1’’) |
6.9(8.0) |
0.14MPa (20PSI) |
1000 |
|
SW-B153 |
15MM (1/2’’) |
3 way valve |
2.6(3.0) |
0.18MPa (25PSI) |
750 |
SW-B203 |
20MM (3/4’’) |
3.4(4.0) |
0.16MPa (23PSI) |
900 |
|
SW-B253 |
25MM (1’’) |
6.5(7.5) |
0.14MPa (20PSI) |
1050 |
|
SW-B152H |
15MM (1/2’’) |
High C.P 2 way valve |
1.7(2.0) |
0.45MPa (65PSI) |
700 |
SW-B202H |
20MM (3/4’’) |
2.2(2.5) |
0.35MPa (50PSI) |
850 |
|
SW-B252H |
25MM (1’’) |
3.0(3.5) |
0.20MPa (30PSI) |
1000 |
|
SW-B153H |
15MM (1/2’’) |
High C.P 3 way valve |
1.7(2.0) |
0.45MPa (65PSI) |
750 |
SW-B203H |
20MM (3/4’’) |
2.6(3.0) |
0.35MPa (50PSI) |
900 |
|
SW-B253H |
25MM (1’’) |
3.4(4.0) |
0.20MPa (30PSI) |
1050 |
