China Factory Newest Daytona Anima 190cc 4 Valve Engine
Product Name |
Daytona Anima 190cc 4 Valve Engine |
| Valve body: | Forged brass |
| Valve seat: | Brass |
| Valve stem: | Chrome-plated brass |
| Actuator shell: | Aluminum |
| Actuator bottom case: | Stainless steel |
| Working voltage: | 24VAC, 110/120VAC, 230VAC; 50/60Hz |
| On/off time: | 13-18s |
| Spring return time: | 4-5s |
| Motor power: | 6.5W, 7 VA |
OEM & ODM |
Acceptable |
| Thread Type | BSP NPT |
Model No. |
Size |
Description |
Kv(Cv) |
Closing pressure |
Weight (g) |
SW-B152 |
15MM (1/2’’) |
2 way valve |
2.2(2.5) |
0.18MPa (25PSI) |
700 |
SW-B202 |
20MM (3/4’’) |
3.0(3.5) |
0.16MPa (23PSI) |
850 |
|
SW-B252 |
25MM (1’’) |
6.9(8.0) |
0.14MPa (20PSI) |
1000 |
|
SW-B153 |
15MM (1/2’’) |
3 way valve |
2.6(3.0) |
0.18MPa (25PSI) |
750 |
SW-B203 |
20MM (3/4’’) |
3.4(4.0) |
0.16MPa (23PSI) |
900 |
|
SW-B253 |
25MM (1’’) |
6.5(7.5) |
0.14MPa (20PSI) |
1050 |
|
SW-B152H |
15MM (1/2’’) |
High C.P 2 way valve |
1.7(2.0) |
0.45MPa (65PSI) |
700 |
SW-B202H |
20MM (3/4’’) |
2.2(2.5) |
0.35MPa (50PSI) |
850 |
|
SW-B252H |
25MM (1’’) |
3.0(3.5) |
0.20MPa (30PSI) |
1000 |
|
SW-B153H |
15MM (1/2’’) |
High C.P 3 way valve |
1.7(2.0) |
0.45MPa (65PSI) |
750 |
SW-B203H |
20MM (3/4’’) |
2.6(3.0) |
0.35MPa (50PSI) |
900 |
|
SW-B253H |
25MM (1’’) |
3.4(4.0) |
0.20MPa (30PSI) |
1050 |
More Products For You To Choose
Certificate of Products
Production line of Product
Exhibition and Customer
Our Services
Before service:
- 1.We have full stock and can deliver within short time.
- 2.OEM and ODM order are accepted, Any kind of logo printing or design are available.
- 3.Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you.
- 4.All of our products are produced by our professional workman and we have our high-work-effect foreign trade team, you can totally believe our service.
After you choose:
- 1. We will count cheapest shipping cost and make invoice to you at once.
- 2. Check quality again, then send out to you at 1-2 working day after your payment
- 3. Email you the tracking no., and help to chase the parcels until it arrive you.
After-sale service:
- 1.We are very glad that customers give us some suggestion for price and products.
- 2.If you have any question,please contact us freely by E-mail or Telephone.
Our Company View
FAQ
Q. what is your payment term?
- A: T/T 30% down payment, balance to be paid before shipment. or L/C.
Q: How do you control the products’ quality?
- A: 1. High quality mold.
- 2. Raw materials control.
- 3. Production process quality control.
- 4. Final inspection.
- 5. Water testing (no leaking).
Q:Could I use my own logo or design on goods?
- A:Yes.Customized logo and design on production are available.
Q: Can I get samples from your factory?
- A: Yes, Samples can be provided.
Q: If products have some quality problem, how would you deal with?
- A: We will responsible for all the quality problems.
