Newest Best Selling Factory Direct Dual Plate Check Valve
Product Name |
Dual Plate Check Valve |
| Valve body: | Forged brass, Hpb59-1 |
| Seal: ball: | EPDM+PTFE |
| Ball: | Stainless steel brass |
| Stem: | EPDM |
| Cover: | PC |
| Rotating shaft: | PA66 |
| Power supply: | 230VAC, 24VAC/DC |
| On-Off time: | 50~90S |
| Angle of rotation: | 90° |
| Manual handle | Available |
| Protect rank: | IP54 |
OEM & ODM |
Acceptable |
| Thread Type | BSP NPT |
Valve body tabel
Model No. |
DN(mm) |
Inch |
Valve type |
Kvs(m3/h) |
Pvmax (MPa) |
Ps (KPa) |
WCBS215 |
DN15 |
1/2” |
2 way |
6.3 |
0.6Mpa |
1400 |
WCBS220 |
DN20 |
3/4” |
2 way |
6.3 |
0.6Mpa |
1400 |
WCBS225 |
DN25 |
1” |
2 way |
10 |
0.6Mpa |
1400 |
WCBS232 |
DN32 |
11/4” |
2 way |
16 |
0.6Mpa |
1400 |
WCBS240 |
DN40 |
11/2” |
2 way |
25 |
0.6Mpa |
1400 |
WCBS250 |
DN50 |
2” |
2 way |
43 |
0.6Mpa |
1400 |
WCBS315 |
DN15 |
1/2” |
3 way |
4.0 |
0.6Mpa |
1400 |
WCBS320 |
DN20 |
3/4” |
3 way |
6.3 |
0.6Mpa |
1400 |
WCBS325 |
DN25 |
1” |
3 way |
10 |
0.6Mpa |
1400 |
WCBS332 |
DN32 |
11/4” |
3 way |
16 |
0.6Mpa |
1400 |
WCBS340 |
DN40 |
11/2” |
3 way |
25 |
0.6Mpa |
1400 |
WCBS350 |
DN50 |
2” |
3 way |
43 |
0.6Mpa |
1400 |
Model No. |
Voltage |
Actuator type |
Output torque |
Consumption |
Valve body |
WVA4-104 |
230VAC±10% |
On/off or 3-piont |
4N.m |
12VA |
DN25,DN20,DN15 |
WVA4-106 |
6N.m |
6VA | DN50,DN40,DN32, |
||
WVA4-110 |
10N.m |
DN50 |
|||
WVA4-204 |
24VAC/DC±15% |
On/off or 3-piont |
4N.m |
3VA |
DN25,DN20,DN15 |
WVA4-206 |
6N.m |
6VA | DN50,DN40,DN32, |
||
WVA4-210 |
10N.m |
DN50 |
|||
WVA4-304 |
24VAC/DC±15% |
0(2)-10VDC |
4N.m |
3VA |
DN25,DN20,DN15 |
WVA4-306 |
0(2)-10VDC&4-20mA |
6N.m |
6VA | DN50,DN40,DN32, |
|
WVA4-310 |
0(2)-10VDC&4-20mA |
10N.m |
DN50 |
