1. Product Overview
HB-SV03B/C is designed for vehicle video monitoring development of a cost-effective video SD card storage devices, The equipment has an ARM high-speed processor, embedded Linux platform, integrated the most advanced technologies, such as H.264 video compression/decompression, wireless network transmission technology and GPS positioning technology of IT field .It can achieve 4 or 8 channels videotaping, the image solution of CIF ,HD1 and D1 is supported by each channel. Equipment has a wealth of extension interface can be scaled up to achieve functional requirements. Industrial product design, safe and practical, flexible installation, easy maintenance and high reliability.
2. Product Feature
| NO. | Product Feature |
| 1 | resolution D1/HD1/CIF can selected |
| 2 | 4channels video input,1 channel audio output,2 channel video output |
| 3 | H.264 video compression, Linux operating system |
| 4 | double yards flow design |
| 5 | selected: GPS module/Beidou module, and 3G/4G communications module, and WIFI module |
| 6 | double SD card storage |
| 7 | 15 seconds delay power data protection function |
| 8 | rich peripherals interface, as: RS485, and RS232, and I/O extended |
| 9 | DC9V~ 36V wide voltage, low-power |
| 10 | industrial products design |
3. MDVR Performance Parameters
| No. | Performance Parameters | Reference Value |
| 1 | Rated Operational Voltage | 12V/24V |
| 2 | Dissipated Power | 6~15W |
| 3 | Operating Temperature | -30℃~+70℃ |
| 4 | Storage Temperature | -40℃~+85℃ |
| 5 | Operating Humidity | 5%~95%(No Condensation Of Moisture) |
| 6 | Acceleration Limit | Acceleration Limit:<4G |
| 7 | Speed Range | Speed Range:0~255km/h |
| 8 | Boundary Dimension | 168mm×125mm×45mm |
| 9 | GPS Chip Parameters | SIRF Start Ⅲ |
| 10 | Frequency | L1 1575.42MHz,C/A Code |
| 11 | Number of Channels | 20 |
| 12 | Tracking Sensitivity | -159bBm |
| 13 | Capturing Sensitivity | -144bBm |
| 14 | Cold Start Positioning Time | 38s(Typical Value) |
| 15 | Warm Start positioning Time | <2s |
| 16 | Positioning Accuracy | <10m(2D RMS) |
| 17 | Antenna Interface | Silver SMA Base |
