MF Induction Heating/Hardening/Quenching Machine Power Supply for gears/bolts/rods
My company
Zhengzhou lan Shuo Electronics Co., Ltd. is located in Zhengzhou high tech Industrial Development Zone, the company since its inception, is committed to the IGBT switching frequency, ultra audio frequency, high frequency induction heating equipment R & D and production, the company spirit of innovation for development, to the quality of survival, and strive for the vast number of users with high quality products, products widely used in stone processing, fasteners, tools, hardware tools, stainless steel products, automobile and motorcycle parts, pipe heat deformation. The main products are LSW - 26, LSW - 50, LSW - 60, LSW - 80, LSW - 100, LSW - 120, -, LSW - 160, -, LSW-300, LSW-200 series, the products sell well, exported to Southeast Asia and other countries and regions .Our company produces induction heating equipment 26KW, 50KW, 80KW, 120KW, 160KW, IF according to your different technical requirements from 200KW-800KW select from the right equipment.
Gear hardening, gear quenching equipment use:
1, to meet the requirements of a variety of hardened gears, shafts and other mechanical components, process maturity, quality assurance, ease of use.
2, sensors using profiling sensors, side scan while water quenching, hardness, hardening depth can meet the requirements.
3, to meet the 150mm diameter shaft surface hardening requirements.
4, to meet the tip diameter of about 250 gear hardening requirements.
Gear hardening, gear quenching equipment features:
1, the use of IGBT-based devices, full-bridge inverter; 100% duty cycle design, can work continuously.
2, the protection function, high reliability; small size, light weight, easy to install, easy to operate.
3, using frequency automatic tracking and closed loop control.
4, replacing heating oxy-acetylene flame, coke furnace, salt bath furnace, gas furnace, oil furnace and so on.
5, remote control and infrared temperature measurement, automatic temperature control, improve the heating quality and simplify the workers to operate.
model |
LSW-120KW |
Work power |
Three phase 380V/50Hz |
Working voltage range (AC) |
340V~420V |
Max input current |
180A |
Max output power |
120KVA |
Oscillation frequency |
50-60KHz |
Continuous load rate |
100% |
Cooling water pressure |
0.1-0.3mpa |
Host weight |
9k0g |
Transformer weight |
100kg |
Host dimensions(L*W*H)mm |
650*480*1440 |
Transformer dimensions (L*W*H)mm |
500*800*580 |
Temperature protection |
50 degrees |
How long is delivery time of your company?
The products will be sent within 5 days.
What is the terms of payment?
T/T D/A Aliexpress West Union
Why should you choose my company?
1.Our factory have been built 10 years, is a direct supplier.
2.With professional and technical personnel, first-class service personnel, a strong work team,
3.reasonable price, bestquality,products are exported to Europe and the United States, Latin America, southeast Asia and other regions
