adjustable solar mounting system solar panel mounting bracket photovoltaic power system
- 3600000 Kilowatt / Kilowatts per Month
- CHINA XIAMEN
- T/T
- Economic price 100w 200w 300w 400watt ABS Housing Solar Cell All In One Integrated Solar Street Light
- Wall Mounted Lifepo4 51.2v 100ah 200ah Lfp battery for Solar System
- 10kwh 20kwh Home Solar Lithium 48v 200ah LiFePO4 Battery
- Residential 5kw Complete Solar Panel Kit For Home Solar Power System With Lithium Or Lead Acid Battery
- Home Hybrid Solar 10KW 40KW 50KW Whole Set Kit Solar Energy System Home Hybrid Solar Power System
- TENTEK TON-5150S stackable solid-state Lithium battery
Product Details
Place of Origin: | Fujian, China | Brand Name: | ReySolar | Model Number: | GM-N0943 |
Specification: | Normal | Application: | Commercial | Output Voltage (V): | 110V/220V |
Load Power (W): | 1000Wp | Solar Power (W): | 300MW | Work Time (h): | 10 years |
Product Description
1. Item Name:adjustable solar mounting system solar panel mounting bracket photovoltaic power system
2. Item No. : GM-N0943
3. Introduction
Ground Solar PV Mounting System GM-N Shape ground Aluminum Solar PV Mounting System is suitable both for concrete foundation and ground screw foundation solar PV power plant. Solar Panels could be installed with layout of Portrait or Landscape. All components are made of 100 percent high-strength aluminum structural parts except the ground screw which leads to good features of good corrosion resistance, light , weight, high strength and delicate appearance. Pre-assambled support structures improve the installation efficiency, saving time and labor cost for the construction of large-scale photovoltaic projects.
4. Technical Data
Design standard: | JIS C8955:2011 |
Max. wind resistance: | 42 m/s |
Max. anti-snow load capacity: | 2.0 KN/m2 |
Installation angle range: | 5°~45° |
Span range: | 2.5 m~3.5m |
Based positioning tolerance | ±10mm |
system installation angle deviation | ±2° |
Installation site | open ground |
Applicable panels | framed or unframed |
Modules direction | portrait or landscape |
rail material | Al6005-T5 |
Bolts&nuts Material | SUS304 |
Ground Screw material | hot galvanized Q235B |
Warranty | 10 years |
Main Feather
Large range of applications: The features of 100% aluminum production structure, light weight, high strength, and good corrosion resistance make the product can be applied to very harsh installation environment.
Compatibility: Suitable for different specifications of PV modules, and the modules can be applied in different ways of arrangement, enabling random swap.
Safety and reliability: With consideration to the load-bearing, wind, earthquake and other factors, and with rigorous calculation and testing the structure ensures safety and reliability.
Easy installation: Most of the parts can be pre-assembled, improving the efficiency of on-site installation, and saving time and labor costs for the construction of photovoltaic projects.
Flexibility and adjustability: Considering of probable construction deviation, the structure is cleverly designed with a flexible regulatory function. The system foundation position errors can be solved by the unique structure of the regulatory function, reducing the difficulty of construction.
7. Test Report
8. Standard Packing
9. About us
Reysolar are a high-tech company in the solar photovoltaic industry, specializing for solar mounting system R&D, production, sales and service. Reysolar are a6000m² manufactory of the Solar Photovoltaic Mounting System supplier which founded in 2002. Reysolar own 300MW production capacity in providing Solar PV Mounting. We Had Cooperate with a Jordan Company for a 1.6MW and other big company in Euro, Asia, Africa.
10. Fair Show
11. Contact Us
Skype: lar
Tel/Fax: +86-592-5668256-807
Mob / Whatsapp : +86-137-9975-0372
Address: 403# Nanshan Rd, Huli District, Xiamen, China 361006
