Power Factor Controller Compensation
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
MAXWEL
Model Number:
RPCF-16
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/shanghai/shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
MAXWEL
Model Number
RPCF-16
Specifications
1. RPCF-16 auto-compensation control2. AC380V/AC220V
3. 139*139MM/113*113MM
4. 16 steps
Product Introduction:
Model: RPCF-16 Reactive Power Auto-compensation Controller. This devices is controlled by microcomputer.Number of channels con-trolled is 2,4,6,8,10,12 available
Product Specification:
| Rated working Voltage: | AC380V or 220V |
| Rated working Frequency: | 45HZ-65HZ |
| Under-voltage prective Value: | 0-999Kvar |
| Under-voltage prective Value: | AC300Vor AC180V |
| sensitivity: | 20mA |
| Rated working current: | AC 0-5A |
| Display power Factor: | Lag 0.001-lead 0.001 |
| Measuring Active Power: | 0-9999KW |
| Output Contact Capacitance: | AC 220V 7A |
| Complete machines contact Consumed power: | 10VA |
| Display: | 4-position red nixie tube |
| Overall Dimension: | 139*139mm |
| Installation Mode: | Inserting type installation rear gear accessories fixed or guide rail installation |
| Connection Mode: | Socket connecting terminal screw fasten protection |
| Class: | Encloure IP 40 |
