XPS Foam Board Production Line

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Application:

Sheet

Plastic Processed:

XPS

Place of Origin:

Shandong, China

Longkou Unity Machinery Equipment Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Port.

Delivery Detail:

Delivery time depends on order quantity.

Application Sheet

Plastic Processed XPS

Place of Origin Shandong, China

Brand Name GBL

Specifications

XPS foam board,named as polystyrene extrusion plastic board (XPS for short),has a flawless closed-pore alveolate structure.

1.For heat preservation of steel structure workshop ,iron sheet house and colored ripply tile;

2.For making up the heat insulation board in the refrige ration storehouse for cold preservation and waterproofing

3.For laying the bedding under the road bed of the highway for buffering and controlling the frost heating of the ground

4.For waterproofing and heat preservation of residential building ,office building ,the factory wall and roof

5.For laying the bedding under the floor for the function of heat insulation ,dampproof and soundproof

6.For heat insulation and heat preservation of the ventilation pipeline of central air conditioner

Main Technical parameters

Model	Unit	GBLXPS-135/150		GBLXPS-150/170		GBLXPS-170/200
Extruder		135/150		150/170		170/200
Heating power	kw	50	52	58	68	78	100
Driving motor power	kw	75	90	90	110	110	132
Thickness of board	mm	20,25,30,40,50,60,75,80		20,25,30,40,50,60,75,100		40,50,60,75,100,120
Width of board	mm	600,900		600,900,1200		600,900,1200
Length of board	mm	1200,1250,2450,2500
Edge of board		SS flat head (SL lap joint, RC rain groove)
Output	kg/h	280-320		300-360		380-500
Installed capacity	kw	300		380		400
Dimensions(L×W×H)	mm	35000×10000×4000		35000×10000×4000		35000×10000×4000
Total weight	T	28		30		33
