XPS Foaming Board Manufacturer

XPS Foaming Board Manufacturer photo-1
US$ 180,000 - 260,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Plates, board
Plastic Processed:
Other, XPS, XPS
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Other, Plates, board
Plastic Processed Other, XPS, XPS
Screw Design Other, Single-screw, Double-screw
Automatic Grade automatic
Place of Origin Shandong, China
Brand Name TY
Model Number TY-135/150
Power(W) 300KW
Dimension(L*W*H) 35X10X4
Weight 28T
Certification CE

Specifications

XPS foaming board manufacturer
XPS insulation board extrusion Line
XPS insluation board with C



XPS foaming board manufacturer

Product Features:

Has a perfect closed-pore alveolate structure.

Its density,water absorption,coefficient of heatconduction and the coefficient of steam pervasion are all lower than those of other board heat preservasion materials

They have the characteristics of strong intensity,light material,qirtight,anticorrosion,aging resistance,low coat,ect.

It had been widely used inthe fields of heat preservation and heat insulation in  the construction indudtry,frost resistance of the highway,airport.square and household fitment.It is the generally known as the best heat preserva,ion materrial in the market at present.

Main Technical Paramerets:

  Model
Unit
GBLXPS-135/150
GBLXPS-150/170
GBLXPS-170/200
  Extruder

135/150
150/170
170/200
  Heating power
kw
50
52
58
68
78
100
  Driving motor power
kw
75
90
90
110
110
132
  Thickness of board
mm
20,25,30,40,50,60,75,80
20,25,30,40,50,60,75,100
40,50,60,75,100,120
  Width of board
mm
600,900
600,900,1200
600,900,1200
  Length of board
mm
1200,1250,2450,2500
  Edge of board

SS flat head (SL lap joint, RC rain groove)
  Output
kg/h
280-320
300-360
380-500
  Installed capacity
kw
300
380
400
  Dimensions(L×W×H)
mm
35000×10000×4000
35000×10000×4000
35000×10000×4000
  Total weight
T
28
30
33


Application of The Produce

  1. For heat preservation of steel structure workshop, iron sheet house and colored ripple title;
  2. For making up the heat insulation board in the refrige ration storehouse for cold preservation and waterproofing;
  3. For laying the bedding under the road bed of the highway for buffering and controlling the frost heating of the ground;
  4. For waterproofing and heat preservation of residential building, office building, the factory wall and roof;
  5. For laying the bedding under the floor for the functions of heat insulation, dampproof and soundproof;
  6. For heat insulation and heat preservation of the ventilation pipeline of central air conditioner.

XPS foaming board manufacturer



XPS foaming board manufacturer

XPS foaming board manufacturer

XPS foaming board manufacturer



XPS foaming board manufacturer
