High Voltage fiberglass telescopic electroscope
Product characteristics:
Using epoxy resin as materials, so it is ultra light, ultra high voltage,high strength.
Applications:
Used for testing the powre frequency voltage on alternating high voltage line and electrical equipment. Function of audible and visual alarm on the safe side.
Specification: 0.1-10kv, 10kv, 35kv,110kv,220kv,500kv. We could produce them as your requirement.
High voltage electroscope
The High voltage electroscope is the necessary security tools for electric system and industrial and mining
enterprise electricity work.
It is used for testing 0.1 KV-750 KV lines or equipment whether running with power frequency voltage,
ensure the personal safety of lineman.
Main technical parameters:
|
Voltage class (kV) |
Retracted length (mm) |
Extended length (mm) |
Effective insulated length (mm) |
Insulated rod node number |
6-10 |
360 |
1000 |
800 |
5 |
35 |
460 |
1540 |
1320 |
5 |
110 |
600 |
2000 |
1600 |
5 |
200 |
800 |
3000 |
2500 |
5 |
500 |
1400 |
8000 |
6750 |
5 |
0.1-10kV |
180 |
900 |
800 |
7 |
Packing: Outer Packing with Cartons
