35kV Composite Post Insulator
Descriptions:
The products are made of glassfiber epoxy core rod,silicone rubber shed and metal fitting. The silicone rubber shed adopt the whole packing pressure technique,and then to solve problem of interface electric spark puncture. Connection of the glassfiber rod and metal fittings, adopts the pressure welding technique of the international advanced level, and have the full automatic sound wave detection of defects system.
Specification:
Model Number |
Rated voltage (kV) |
Rated mechanical bending load (kN) |
Structure height (mm) |
Insulating distance(mm) |
Min nominal creep distance (mm) |
Diameter of shed (mm) |
Lightning impulse withstand (kV) |
Power frequency wet withstand voltage(virtual value)kV |
FZSW-10/4 |
10 |
4 |
215 |
125 |
290 |
100/90 |
75 |
42 |
FZSW-35/5 |
35 |
5 |
400 |
353 |
780 |
145/100 |
185 |
95 |
FZSW-66/8 |
66 |
8 |
760 |
630 |
1940 |
210/170 |
410 |
185 |
FZSW-110/10 |
110 |
10 |
1240 |
1070 |
3250 |
210/170 |
500 |
230 |
FZSW-220/6 |
220 |
5 |
2200 |
2030 |
6450 |
210/170 |
1000 |
395 |
Our Service:
· Composite post insulator sample is available .
· Prompt attention to any request from you.
· Outstanding after-sales service.
· Favorable discount for our distributor and regular customers.
· Varied express and logistics are available.
If you want to know more details, pls do not hesitate to contact us!!!
