The pricture shows our new type product named"Chromium-contained ceramic fiber blanket".
Some exact information of it as below:
Item:ceramic fiber blanket(Spun)
Temp.1500C Degree
Size:25x610x7200mm
Density:128kg/m3
Color:light green
Net weight:14KG/ROLL
Packing:inner plastic bags;outer carton box;1roll/carton box
1X40HC can store 525CTNS
Application range:
1,Industrial building material furnace, heating plant and high-temperature tube wall liner.
2, Electric power boiler, turbomachine and nuclear electricity heat insulation
3, Wall liners for industrial high-temperature conversion unit and heating equipment
4, Fireproofing and heat insulation of high-rise building
5,Heat insulation of furnace door and head cover
6,High-temperature filtrating material
Product Item |
NBY-1500 |
|
Specification temperature OC |
1500 |
|
Max working temperature OC |
1350 |
|
Color |
Green/blue |
|
Density(kg/m3) |
64-160 |
|
Liner shrinkage(%)(OC*24h), Density 128kg/m3 |
≤-4 (1400OC) |
|
|
Thermal Conductivity (W/n.k)
|
96KG/m3 128KG/m3 160KG/m3 0.10(400°C) 0.09(400°C) 0.08(400°C) 0.15(600°C) 0.12(600°C) 0.11(600°C) 0.23(800°C) 0.20(800°C) 0.19(800°C) 0.30(1000°C) 0.26(1000°C) 0.22(1000°C) 0.45(1200°C) 0.35(1200°C) 0.33(1200°C) |
|
|
Average Tensile Strength kpa Density 128 kg/m3 |
45 |
|
|
Chemical composition % |
AL2O3 |
42 |
AL2O3+SIO2+ ZrO2 |
99 |
|
ZrO2 |
2.8 |
|
Fe2O3 |
0.15 |
|
Na2O3+K2O |
0.10 |
|
Product Size (mm) |
Size 14640*610*13,7300*610*25,4880*610*38,3600*610*50 |
|
