Advertising letter laser welding 200W factory CE laser welding machine price semi automatic welding machine
- 100 Set / Sets per Month
- Shenzhen
- T/T Credit Card
- Multi-usage co2 laser marking machine engrave non-materials arts and gifts food package product date code marking plastic switch
- Automatic laser welding machine no welding penetration continuous welding widely used in sanitary battery glasses hardware
- Fast and high efficiency fiber laser marking machine used in marking rings bracelets mugs watches sanitary ware IC keyboard etc
- mechanical tools cutting machine for Acrylic/wood CO2 laser cutting machine 1390 laser cutting machine
- wholesale distributors wanted laser wood cutting machine price fabric laser cutting machine laser cutting machine price
- desktop cnc machine | LED channel letters welding machine | robotic LOGO welding machine price
Product Details
Condition: | New | Place of Origin: | Guangdong, China | Brand Name: | Hailei |
Model Number: | HL-G-200W,HL-G-400W | Single Pulse Energy: | 90J,120J | Pulse Width: | 0.5-20ms |
Wavelength: | 1064nm | Focal Spot Diameter: | 0.2-2mm | Max. Output Power: | 200W,400W |
Dimensions: | 600*1000mm | Usage: | Laser Welding | Power(W): | 7KW |
Certification: | Other, ISO9001:2008 | Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Laser welding machine laser welder
Features:
(1) Welding head can be moved up and down, front and back, left and right to realize regulating and positioning, it is suitable for welding of font edge height 0.5-20cm, operability is greatly increased.
(2) The optical path and the power control system use independent design, convenient movement and suitable for a variety of venues and does not affect the font welding.
(3) Welding letter table horizontal direction is using track ball screw, it can be applied to large, small font welding, the operation table can be easily removable, and has very high precision and stability. The center positioning system can realize accurate welding for various characters.
(4) The machine control system can control laser power waveform in precision, and the system set up optimization waveform values for different material. As long as select the corresponding material, it can achieve the best welding effect.
(5) Small heat affected area, does not cause deformation, better welding depth, firm welding, better melted, leaving only 0.2mm~0.5 trace inside but not in font surface. The convex part of solution material in the bath can bind of the substrate material without convex depression phenomenon.
Technology Parameter:
Model | HL-G-200W | HL-G-400W |
Maxiumn laser power(W) | 200 | 400 |
Laser wavelength(nm) | 1064 | 1064 |
Single pulse energy(J) | 90 | 120 |
Welding frequency(HZ) | 0.5-100 | 0.5-500 |
Welding depth(mm) | 0.1-2.5 | 0.1-3.5 |
Pulse width(ms) | 0.5-20 | 0.5-20 |
Spot size(mm) | 0.2-2 | 0.2-2 |
Power required | single-phase 220v/50Hz | three-phase 380V50Hz |
Control System | PLC/IPC | PLC/IPC |
Workbench(mm) | 600*1000(customize) | 600*1000(customize) |
1.Air or Sea shipping,Cheap Price, but will take a little more time to reach you.
2.Equipment will be packed into the standard wooden cartons, suitable for vessel or air transport, and marked the universal label, shipping marks etc.
(1) Warranty and Service included:
a. Hardware: 1 year on all parts and labor;
b. Software: whole life on update for free.
c. Maintenance and technological support: whole life.
(2) Training:
a. 3--4 days free training for the whole system in Seller’s company.
b. If customer needs our technician give the training abroad, the customer need charge for the transportation and accommodation fees of engineer;
Including: how to set up the equipment;
how to debug the light route;
how to use the software and operate the equipment;
how to replace the bad material and spare parts, etc;
how to maintain the equipment;
how to estimate and settle the problem, and analysis the reason.
1.Q: How can you guarantee that I have a good sale on this product?
A: Our products are professional, high quality and competitive price. We also offer professional technology and after-sale service.
2. Q: How can I get the sample to check the quality?
A: If you want to mark sample to check the quality, pls kindly send us the sample for testing.
3. Q: How long can I expect to get the sample?
A: We ensure that the welding samples could be done within 1-2 days once we receive the sample from your side.
Pls let us know:
1. What kind of machine you need?
2. The information about the material you want to process.
3. What is your business scope? Are you end user or distributor?
We will be very happy to help you in any way we can. Pls don't hesitate to LEAVE MESSAGE to me.
