Model Number TPIC8101DW
Type Other, Sensor Interface
Brand Name TEXAS INSTRUMENTS
Place of Origin Taiwan, China
Package SOIC-20

Specifications

TPIC8101DW:
1.Sample Support
2.Most Competitive Price
3.Fast Delivery
4.Quality Guarantee of Original & New

Integrated Circuit:   TPIC8101DW

Specifications:

1. Original & New Only
2. Most Competitive Price & Best Service
3. Sample Supply
4. Knock Sensor Interface

Applications:   Knock Sensor Interface

Electronic Components IC Chip TPIC8101DW

Electronic Components IC Chip TPIC8101DW

Description:

The TPIC8101 is a dual-channel signal processing IC for detection of premature detonation in combustionengine. The two sensor channels are selectable through the SPI bus. The knock sensor typically provides anelectrical signal to the amplifier inputs. The sensed signal is processed through a programmable band-pass filterto extract the frequency of interest (engine knock or ping signals). The band-pass filter eliminates any enginebackground noise associated with combustion. The engine background noise is typically low in amplitudecompared to the predetonation noise.

The detected signal is full-wave rectified and integrated by use of the INT/HOLD signal. The digital output fromthe integration stage is either converted to an analog signal, passed through an output buffer, or be read directlyby the SPI.



This analog buffered output may be interfaced to an A/D converter and read by the microprocessor. The digitaloutput may be directly interfaced to the microprocessor.



The data from the A/D enables the system to analyze the amount of retard timing for the next spark ignition timingcycle.



With the microprocessor closed-loop system, advancing and retarding the spark timing optimize the load/RPMconditions for a particular engine (data stored in RAM).



Features:

· Dual-Channel Knock Sensor Interface

· Programmable Input Frequency Prescaler (OSCIN)

· Serial Interface With Microprocessor (SPI)

· Programmable Gain

· Programmable Band-Pass Filter Center Frequency

· External Clock Frequencies up to 24 MHz− 4, 5, 6, 8, 10, 12, 16, 20, and 24 MHz

· Programmable Integrator Time Constants

· Operating Temperature Range −40°C to125°C applications

· Engine Knock Detector Signal Processing

· Analog Signal Processing With Filter Characteristics
