Bridgelux 3W SMD LED chip

FOB Price

USD $0.28 - $0.33 / Piece

50 Pieces(Min.Order)

Supply Ability 100000 Piece / Pieces per Month
Port shanghai
Payment Terms:Credit Card

Request Sample Customized Request Download Product Catalog

Get lowest price Inquiry Basket

You May Like

Product Details

Model Number:	TDS-P003	Chip Material:	InGaN	Emitting Color:	Other, Warm/pure/cool white
Luminous Intensity:	80lm/w	Luminous Flux(lm):	200-220lm	Optical Attenuation(%):	0.0001
Power:	Other, 1-3W, 3W	Power Dissipation:	3	Color Rendering Index(Ra):	80
Color Temperature:	2000-20000K	Operating Temperature(℃):	-30, 80	Storage Temperature(℃):	-30, 120
Place of Origin:	Jiangsu, China	Brand Name:	TDS	Certification:	CE

Product Description

Product Description

Name	Model	Color	Angle(°)	wave length/Color (IF=700mA)		Luminous flux (IF=700mA)		forward voltage (IF=700mA)
				wave length/Color (IF=700mA)		Luminous flux (IF=700mA)		forward voltage (IF=700mA)
				MIN	MAX	MIN	MAX	MIN	MAX
3 W	TDS-P003L4M03	RED	90/120/140	620nm	625nm	80	100	2.5	2.6
	TDS-P003L4N03	RED		660NM		60	70	2.5	2.6
	TDS-P003L4L03	YELLOW		590nm	595nm	80	90	2.8	3.2
	TDS-P003L4C04	BLUE		450nm	460nm	40	50	3.8	4.2
	TDS-P003L4C05	BLUE		440nm	445nm	40	50	3.8	4.2
	TDS-P003L4F07	GREEN		520nm	525nm	180	190	3.8	4.2
	TDS-P003L4O10	WHITE		2000K	3000K	200	220	3.8	4.2
	TDS-P003L4Q10	WHITE		3000K	4000K	200	220	3.8	4.2
	TDS-P003L4S10	WHITE		4000K	5000K	200	220	3.8	4.2
	TDS-P003L4U10	WHITE		5000K	6000K	200	220	3.8	4.2
	TDS-P003L4U11	WHITE		6300K	6800K	200	220	3.8	4.2
	TDS-P003L4U13	WHITE		7000K	9000K	200	220	3.8	4.2
	TDS-P003L4U14	WHITE		13000K	15000K	200	220	3.8	4.2
	TDS-P003LUV03	UV	390-400NM / 400-410NM / 410-420NM / 430-440NM
	TDS-P003LUV02	IR	365NM
	TDS-P003LIR05	IR	730NM 770NM
	TDS-P003LIR06	IR	810NM 850NM 940NM

Applications:

All general Indoor lighting and outdoor lighting:

Led Spotlight , Led bulb , under water lamp , under ground light , led fluorescent tube , Led ceiling light , Led down

light , Led garden light , Led decorative light , Led street light , high power led bay light , Led flood light , Led projector

, Led dancing light , Led surgery light , Led desk light , Led tunnel light , Led aquarium light , plant growing light ,

led sign board , Led traffic light and etc.

LED Dimension
