CREE COB LED 1304 1507 1512 1820 High Power LED

PRODUCT DESCRIPTION

The XLamp® CXA1304 LED array expands Cree LED’s family of high‑flux, multi‑die arrays in a smaller, easy‑to‑use platform. With XLamp LED lighting‑class reliability, the CXA1304’s small, uniform emitting surface enables both directional and non‑directional lighting applications including lamp retrofit and luminaire designs. Available in 2-step, 3‑step and 4-step color consistency, and featuring a 6‑mm optical source, the CXA1304 brings new levels of flux and efficacy to this form factor. The CX Family LED Design Guide provides basic information on the requirements to use the CXA1304 LED successfully in luminaire designs.

FEATURES

• Available in 4-step, 3‑step and 2-step EasyWhite® bins at 2700 K, 3000 K, 3500 K, 4000 K & 5000 K CCT and 4-step EasyWhite bins at 5700 K & 6500 K CCT

• Available in ANSI white bins at 4000 K, 5000 K, 5700 K & 6500 K CCT

• Available in 70-, 80-, 90- and 93‑minimum CRI options

• Forward voltage options: 9‑V class, 18‑V class & 36‑V class

• 85 °C binning and characterization

• Maximum drive current: 1000 mA (9 V), 500 mA (18 V), 250 mA (36 V)

• 115° viewing angle, uniform chromaticity profile

• Top-side solder connections

• Thermocouple attach point

• NEMA SSL-3 2011 standard flux bins

• RoHS and REACH compliant

• UL® recognized component (E349212)

ORDER CODE

CXA1304-0000-000C00A227F CXA1304-0000-000C00A435H CXA1304-0000-000C00C450F CXA1304-0000- 000N0Y9435H CXA1304-0000-000C0HB250H CXA1304-0000-000N00A40E8 CXA1304-0000-000N0UA450F CXA1304-0000-000N0Y940E6 CXA1304-0000-000C0Y840E7 CXA1304-0000-000C0Y9230F CXA1304-0000- 000C0Y840E8 CXA1304-0000-000C0UA250F CXA1304-0000-000N00A40E7 CXA1304-0000-000N00B435F CXA1304-0000-000N00B440F CXA1304-0000-000N0HB250H CXA1304-0000-000N0HB450F CXA1304-0000- 000N0HC20E3 CXA1304-0000-000C00C240F CXA1304-0000-000C0HA440F CXA1304-0000-000C0HB20E5 CXA1304-0000-000C0Y920E6 CXA1304-0000-000C0HB440H CXA1304-0000-000C0HB450F CXA1304-0000- 000N0Y8427H CXA1304-0000-000C0Y9230H CXA1304-0000-000N0UA20E5 CXA1304-0000-000N0UA250F CXA1304-0000-000C00A427F CXA1304-0000-000C00B227F CXA1304-0000-000N0Y9230F CXA1304-0000- 000C0Y9235F CXA1304-0000-000N0HB20E3 CXA1304-0000-000N0HB20E5 CXA1304-0000-000N0UA240F CXA1304-0000-000N0UA450H CXA1304-0000-000C0Y9235H CXA1304-0000-000C0UA450F CXA1304-0000- 000C0Y9435H CXA1304-0000-000C0Y8427H CXA1304-0000-000N0Y8227F CXA1304-0000-000C0UA20E5 CXA1304-0000-000N00B450H CXA1304-0000-000N00C240F CXA1304-0000-000N0Y9435F CXA1304-0000- 000C0UA450H CXA1304-0000-000C0Y8427F CXA1304-0000-000C0Y9435F CXA1304-0000-000C00A40E8 CXA1304-0000-000C00A430F CXA1304-0000-000C0HC250F CXA1304-0000-000N00B240H CXA1304-0000- 000N00B440H CXA1304-0000-000N00B450F CXA1304-0000-000C00C450H CXA1304-0000-000C0HB40E5 CXA1304-0000-000C0HA440H CXA1304-0000-000C0HB20E3 CXA1304-0000-000C0HB440F CXA1304-0000- 000N00B235F CXA1304-0000-000N00B20E5 CXA1304-0000-000N00B40E6 CXA1304-0000-000C00B20E7 CXA1304-0000-000C00B235F CXA1304-0000-000C00B40E5 CXA1304-0000-000C00B435F CXA1304-0000- 000C00A435F CXA1304-0000-000C00B20E6 CXA1304-0000-000C00B450H CXA1304-0000-000C00C250F CXA1304-0000-000N00A227F CXA1304-0000-000N00A40E6 CXA1304-0000-000N00B435H CXA1304-0000- 000N00C20E3 CXA1304-0000-000N00C450F CXA1304-0000-000N0HB250F CXA1304-0000-000N0HB440F CXA1304-0000-000C00A20E8 CXA1304-0000-000C00A40E7 CXA1304-0000-000C00A430H CXA1304-0000- 000C00B440H CXA1304-0000-000C00C40E3 CXA1304-0000-000C0HA40E5 CXA1304-0000-000N0Y920E6 CXA1304-0000-000N0Y840E7 CXA1304-0000-000N00A430H CXA1304-0000-000N00B235H CXA1304-0000- 000N00C250F CXA1304-0000-000N0HB40E5 CXA1304-0000-000C00A40E6 CXA1304-0000-000C00B20E8 CXA1304-0000-000N0HB440H CXA1304-0000-000N0HB450H CXA1304-0000-000C0U940E5 CXA1304-0000- 000N0Y9235F CXA1304-0000-000N0U9440H CXA1304-0000-000N00A427F CXA1304-0000-000N00A427H CXA1304-0000-000C00B235H CXA1304-0000-000C0HB450H
