We are the IDH of NXP , here the details of the part :
Description:
1.Highly integrated and powerful advanced basestaion IC,ABIC,suited for vehicle immobilisation applications.
2. Incorporates all necessary functions to facilitate reading and writing of transponders.
3.The ABIC,PCF1991employs a unique AM/PM demodulation techique .
4.The carrier frequency can be derived from an on-chiposcillator or an external clock source.
5.The device enables system diagnostic functions byantenna fail detection features.
Features:
1.Extended system operating range due to powerfulAM/PM demodulation technique 2. Ideally suited for "Intelligent Antenna" and "ActiveAntenna" architectures
3.High antenna drive capabilities, CW: 200mAp
4.Low antenna driver output resistance, 3.5 om
5.Excellent receiver sensitivity, 2mVpp
6.Large receiver dynamic range
7.Programmable clock divider, modulator, receivergain and filter characteristics
8. Fast "read after write" receiver settlingcharacteristics
9. On-chip receive EMI filter
10. Antenna failure mode detection
11.Few external components
12. Operating supply voltage: 4.5 to 5.5 V
13. Power down mode: 7µA @ 5.5 V
14.14-pin SO package
Applications:
1.vehicle immobilisation applications
2.can be used in combination withcommonly available transponder that employ ASKmodulation 3.on-chiposcillator an external clock source.
4.transponder
1.Trading terms are Ex-work Shenzhen or Hongkong.
2.We will ship the goods within 3 working days after the payment received.
3.We can ship the goods to worldwide by DHL/FEDEX/UPS/TNT/EMS or other best possible way. Please also contact us directly if you have preferred ways.
4.We are not responsible for any accidents, delays or other issues happened during the transportation. But we will try our best help you together solve them.
5.Any import fees or charges are the buyer’s responsibility.
1.All goods are offered 30days quality guarantee.
2.If the goods is defective or negative, please notify us within 3days of delivery.
3.All the refund or replaced goods need provide third party test report or certification.
4.Any goods must be returned in their original conditions to qualify for a refund or replacement.
1.We are responsible for all the goods from us. If you have any questions about the goods, you can contact us freely in any time.
2.As add-valued service, we can help our customers arrange their goods combination shipment or other goods they want from here China. We also can help our customer pay to their many different suppliers here.
Anything you need us, we are just be here for you.
| Part No. | Mfg. | Package |
| PCF7991AT/1081 | NXP | SOP |
| PCF7936AA/3851/C | NXP | SOP |
| TJA1040T/VM | NXP | SOP |
| TJA1055T | NXP Semiconductors | SOP |
| BAT54-04 | infineon | SOT23 |
| BZX84-C4V7 | NXP | SOT23 |
| GDZ30B-V-GS08 | Vishay | SOD323 |
| MBRS3201T3G | ON | DO214 |
| S1J-E3 | Vishay | DO214 |
| S1J-13-F | Diodes inccorprated | DO214 |
| PESD1CAN | NXP | SOT23 |
| AT24C02C-SSHM-T | ATMEL | SOP |
| UUR1E101MCL1GS | Nichicon | DIP |
| UUR1V221MNL1GS | Nichicon | DIP |
| TLE42744DV50 | Infineon | TO252 |
| HSML-A100-Q00J1 | avagotech | LED |
| LP T67K-F1G2-25 | OSRAM | LED |
| LT T67C-S2U1-35 | OSRAM | LED |
| LY T68B-T2V1-26 | OSRAM | LED |
| PKM22EPPH2001-B0 | Murata | SMD |
| PKM22EPPH2001-B0 | Murata | SMD |
| BC817 | NXP | SOT23 |
| FDN360P | Fairchild Semiconductor | SOT23 |
| BC807-25 | NXP Semiconductors | SOT23 |
| BCP51 | FAIRCHILD | SOT223 |
