Ribbed belt(poly v-belt)
Rubber Ribbed V with both peace with both the advantages of both flat with the soft, strong features, and with V compact, high-performance advantages. Factory production models of rubber V-ribbed belts, with wear, fatigue-resistant, long-life advantages.
| Production Type | Pb | Thickness (approximation) | Slot bottom(max) | Height | Length Range(inch) | Length Range(mm) | Angle | |
| PH | 1.6 | 2.7 | 0.15 | 2.8-3.0 | ⁄ | ⁄ | 40º | |
| PJ | 2.34 | 3.8 | 0.20 | 3.7-4.1 | 13''-120'' | 330-3048 | 40º | |
| PK | 3.56 | 5.0 | 0.25 | 4.2-4.5 | 22''-120'' | 559-3048 | 40º | |
| PL | 4.7 | 9.0 | 0.40 | 6.8-7.2 | 50''-160'' | 1270-4064 | 40º | |
| PM | 9.4 | 14.5 | 0.75 | 15.5-16.0 | 100''-160'' | 2540-4064 | 40º |
APPLICATIONS:
PJ -Light weight, electric motors, Air compressors, ice cream machines,
excercise equipment.
PK -Auto serpentine,available in all lengths and custom cut-widths.
PL -Gas Compressors, Diesel Engines,Agriculture equip.
PM -Heavy equip.& compressors.
Our company is specialized in manufacturing automotive V belt, ribbed belts, motorcycle V belt, automotive timing belt, industrial variable speed belt, banded v-belt, narrow V belts, and butyl pouches and other products.
POLY v belt is one of our main products.
Characters:
1. good obdurability,cormpoact ,high effciency
2.High power transmission capability
3.Especially be applicable be high speed,high tweak large and medium-sized equipments.
poly-rib belt Material skeleton: high modulus polyester line
poly-rib belt Wrapped: structured cotton canvas
poly-rib belt Rubber: neoprene with excellent performance
poly-rib belt Features: flexible high strength, elongation to use small, with the head of the degrees, and drive a very flat FISHER, transmission efficiency, compact root drive a few.
poly-rib belt Uses: particularly suitable for high-power, there is duplication and instant overload, gear to For compact, high speed, such as the use of harsh conditions to make mechanical power transmission Use, but also the driving force available for general use.
Noted: Our company can produce double sided poly v-belts specifation model number and material (CR,EDPM) to take, the effective length is 500mm~4000mm.
