API-7-1 QJZ Mechanical Drilling Jar For Fishing Tools

Name: API-7-1 QJZ Mechanical Drilling Jar For Fishing Tools
Brand: DYQX
SKU: 102109027

API-7-1 QJZ Mechanical Drilling Jar For Fishing Tools thumbnail-1

API-7-1 QJZ Mechanical Drilling Jar For Fishing Tools photo-1

US$ 1000.00 - 1000.00 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

DYQX

Model Number:

API

Contact Supplier Request Quote Chat Now

Dongying Qixiang Import & Export Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

China Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name DYQX

Model Number API

Type Drill Pipe

Machine Type Drilling Tool

Certification API

Material Carbon Steel

Processing Type Forging

Use Well Drilling

Specifications

1).API STANDARD
2).SAFE AND RELIABLE
3).DELIVERY ON TIME.
4).COMPETITIVE PRICE
ALL DEPENDS ON ENOUGH CREDIBILITY.

QJZ type mechanical drilling jar is a kind of fully-mechanical jarring tools.It can release the drilling tools sticking accidents by providing a up and down jarring force.Basically,it is part of the drill stem,whenever needed,the jarring force can increase the working efficienc.

Up-jarring working principle

It show us the jarring state unlocked after be adjusted when it comes to the jarring position the moving axis should snap in the inside threads of the slips.The outer thread of the slips and inside sleeve are under the friction state with.When lifting the drill stem,the upper sub,upper control sleeve,middle sleeve lower control sleeve,lower regularing sleeve,spring type inside sleeve,spring middle sleeve,and spring outer sleeve will move upward while friction sleeve keep still.The slips can be opened when its outer thread top touch the friction sleeve's teeth,at the moment the teeth of the axis will move out from the slips' inside teeth, Then stored power will release and give a up and down double- way force,the the tool will return to the state the ready to jarring position.Repeat the following operation,we can release the sticking drilling tools.

Lower jarring working principle

There are a set of spring sleeve on the top of the slips.When the stem give a pressure on the

jar,it can pass through the upper sub,upper control sleeve,upper regularing sleeve to work on the spring type inside sleeve,spring middle sleeve,and spring outer sleeve.Slips will move upwards while the friction sleeve keep still,until reach the predetermination position,the teeth top of the slips will touch the teeth of the friction sleeve,slips will open to let the moving axis release from the slips teeth,the down-way jarring force against the upper jarring force.
