Home > Industrial Equipment & Components > Filtration Equipment & Parts > Machine Oil Purifier > Portable Used Transformer Oil Purifier With High Quality

Portable Used Transformer Oil Purifier With High Quality

Name: Portable Used Transformer Oil Purifier With High Quality
Brand: ASSEN
SKU: 102107367
Availability: InStock

Portable Used Transformer Oil Purifier With High Quality thumbnail-1

Portable Used Transformer Oil Purifier With High Quality thumbnail-2

Portable Used Transformer Oil Purifier With High Quality thumbnail-3

Portable Used Transformer Oil Purifier With High Quality thumbnail-4

Portable Used Transformer Oil Purifier With High Quality thumbnail-5

Portable Used Transformer Oil Purifier With High Quality thumbnail-6

Portable Used Transformer Oil Purifier With High Quality photo-1

Portable Used Transformer Oil Purifier With High Quality photo-2

Portable Used Transformer Oil Purifier With High Quality photo-3

Portable Used Transformer Oil Purifier With High Quality photo-4

Portable Used Transformer Oil Purifier With High Quality photo-5

Portable Used Transformer Oil Purifier With High Quality photo-6

US$ 22,000 - 35,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Flow:

12000LPH

Working Pressure:

0.4MPA

Contact Supplier Request Quote Chat Now

Chongqing Assen Power Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Flow 12000LPH

Working Pressure 0.4MPA

Place of Origin Chongqing, China

Brand Name ASSEN

Model Number ZYD-200

Usage Transformer Oil

Voltage 380 220

Power(W) 88KW

Dimension(L*W*H) 1950*1500*1720MM

Weight 950

Certification ISO, CE

After-sales Service Provided Engineers available to service machinery overseas

portable used transformer oil purifier with high quality

Product Application

Our ZYD Used transformer oil purifier machine can do:

1.Purify and dehydrate used transformer oil.

2.Improve the dielectric strength more than 75KV.

3.Be widely used for power equipments(transformer,switch,mutual etc)

4.Vacuum oiling for transformer.

5.Remove the impurities(particles, water, sludge, acidity, gas etc )

6.By removing contaminants from insulating oils, they restore the oils dielectric properties, and at the same time extend the useful life of your electrical equipment.

Product Features

1. Unique and highly efficient dewatering and degassing device, it adopted a large area three-dimensional flash evaporation and mature film evaporation technology to rapidly remove the free and dissolved water and gases from used and waste insulating oils.

2. Precise filtration system, high quality filter element, multi-stage filtration system levels, can effectively remove the mechanical impurities from the insulating oils.

3. Electrical heating system is the optimized pipeline design to ensure uniform heating and stable oil temperature.

4. Automatic constant temperature control device, automatic liquid level control device, automatic defoaming device, automatic pressure protection device and excellent configuration can ensure the equipments in high performance.

5. Work online and the indicators display running.

6. Unattended operation with low working noise and longtime free maintenance.

7. A complete machine safety interlock protection system, discharge oil system, vacuum system and the heating system interlock, to avoid the adverse effects of misuse.

Product Description

Used transformer oil purifier

Transformer is one of the main asset in the electrical power industry which needs to be maintained for guaranteed uninterrupted power transmission in order to get assured revenue benefits.
Transformer life mainly depends on the quality of oil volume it contains.
Transformer oil conditioning may also include to some extent improving the acidity of the oil.
A good oil purification system is able to deliver filtered oil with parameters as per the standard specification.

Used transformer oil purifier's Technical Data:

Parameters		Unit	ZYD-30	ZYD-50	ZYD-100	ZYD-150	ZYD-200	ZYD-250	ZYD-300
Flow		L/min	30	50	100	150	200	250	300
Working vacuum		MPa	0.08 ~ 0.099
Working Pressure		MPa	≤0.3
Breakdown Voltage		KV	≥75
Water Content		PPM	≤3
Gas Content		%	≤0.01
Impurity Size		μ	≤5
Temperature Range		°C	20 ~ 80
Power			Three Phase 50HZ380V(as per the customer's requirements)
Working Noise		dB(A)	75	75	75	80	80	80	80
Heating Power		kW	30	30	45	60	75	90	120
Total Power		kW	35.5	37.5	52.5	71.4	86.5	102.5	135
Inlet/Outlet		mm	φ25	φ32	φ42	φ50	φ50	φ60	φ60
Weight		kg	600	800	1050	1400	1800	2000	2200
Overall	Length	mm	1050	1100	1200	1450	1600	1800	1900
	Width	mm	750	800	950	950	1100	1200	1200
	Height	mm	1350	1400	1500	1650	1800	1900	1900

Structure Chart:

The oil technical data after treatment:

Item	Guarantee indexes
Moisture content	≤3PPM
Impurity size	≤1 micron
Gas content	≤0.1%
Breakdown voltage	≥75

Used transformer oil purifeir's Advantage:
Good vacuum pressure and high flow rate. This product makes bridge with the electric equipments. Vacuum, filtration and oil injection can work independently and also they can work together. As the oil purifying nanotechnology, this machine can treat oil more quickly and more completely, and makes the oil limiting voltage-withstand value much higher than the ordinary vacuum oil purifier

Packaging & Shipping

Our Services

Your inquiry related to our products or prices will be replied in 24 hours.
Well-trained and experienced staffs to answer all your enquires in fluent English.
Professional service from well-trained and experienced staffs is customers’ best choice to secure good communication, on time delivery, reliable warranty etc.
OEM is available for Anern Products.
Protection of your sales area, ideas of design and all your private information.

Our Customers

FAQ

Q: How can we achieve drying without elevated heating of the insulation material for transformers?
A: Drying of insulation materials can be achieved at low temperature and low pressure levels. The pressure levels and temperature levels for drying vary for distinct material. At low pressure or under vacuum the rate of water vapour evaporation is accelerated if sufficient heat is provided to the insulation material. Thus we can achieve a good drying of insulating material if the material is suitably heated and subjected to vacuum.
