Home > Industrial Equipment & Components > Filtration Equipment & Parts > Machine Oil Purifier > Finely Processed Transformer Oil Filtering System Plant

Finely Processed Transformer Oil Filtering System Plant

Name: Finely Processed Transformer Oil Filtering System Plant
Brand: ASSEN
SKU: 102105995
Availability: InStock

Finely Processed Transformer Oil Filtering System Plant thumbnail-1

Finely Processed Transformer Oil Filtering System Plant thumbnail-2

Finely Processed Transformer Oil Filtering System Plant thumbnail-3

Finely Processed Transformer Oil Filtering System Plant thumbnail-4

Finely Processed Transformer Oil Filtering System Plant thumbnail-5

Finely Processed Transformer Oil Filtering System Plant thumbnail-6

Finely Processed Transformer Oil Filtering System Plant photo-1

Finely Processed Transformer Oil Filtering System Plant photo-2

Finely Processed Transformer Oil Filtering System Plant photo-3

Finely Processed Transformer Oil Filtering System Plant photo-4

Finely Processed Transformer Oil Filtering System Plant photo-5

Finely Processed Transformer Oil Filtering System Plant photo-6

US$ 9,500 - 18,500 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Flow:

3000LPH

Working Pressure:

0.4MPA

Contact Supplier Request Quote Chat Now

Chongqing Assen Power Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

CHONGQING

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Flow 3000LPH

Working Pressure 0.4MPA

Place of Origin Chongqing, China

Brand Name ASSEN

Model Number ZYD-50

Usage Transformer Oil

Voltage 400 380 220

Power(W) 48KW

Dimension(L*W*H) 1750*1050*1350MM

Weight 800

Certification CE, ISO

After-sales Service Provided Engineers available to service machinery overseas

finely processed transformer oil filtering system plant

Product Application

ASSEN transformer oil filtering system machine adopts interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically. Water, gas, particles and other harmful things will contaminate dielectric strength and insulating performance of transformer oil.

Series ZYD transformer oil filtering system machine combines with unique and advanced vacuum dewatering, degassing components and three grades filtering system for rapidly and effectively separating water, gas, particles from oil. ZYD transformer oil filtering system machine also can purify switch oil, mutual inductor oil, cable oil, circuit breaker oil, capacitor oil, insulating oil and so on. This transformer oil filter machine is the most effective, durable, and user-friendly Hi-Vacuum system on the market today.

Product Features

1. Two pumps: Vacuum pump and booster pump
2. Three-stage filter system
3. Z-shape Heater to make the heating uniformity
4. Installing oil-level floating ball and double-infrared liquid level automatic controller to control the oil level
5. Foam sensor to avoid oil leaking
6. Temperature Controller to protect the machine
7. Suitable oil filtration machine for high voltage transformer
8. Large filtration area, high capacity of holding impurities
9. Two vacuum separator to increase separating size and time and ensure the drying degree and improve dielectric strength which is higher than 75 KV.
10. Doing online oil purification of substations over 110 KV.
11. Independent function of vacuum oil filling and drying.
12. Duplex stereo flash evaporation technology
13. Equipped with pressure protective system and interlocked protective system to connect oil pump, heater and liquid level controller. If there has any fault, this oil filter will be power off automatically.
14. Saving energy and time

Product Description

transformer oil filtering:

Transformer is one of the main asset in the electrical power industry which needs to be maintained for guaranteed uninterrupted power transmission in order to get assured revenue benefits.
Transformer life mainly depends on the quality of oil volume it contains.
Transformer oil conditioning may also include to some extent improving the acidity of the oil.
A good oil purification system is able to deliver filtered oil with parameters as per the standard specification.

transformer oil filtering's Technical Data:

Parameters		Unit	ZYD-30	ZYD-50	ZYD-100	ZYD-150	ZYD-200	ZYD-250	ZYD-300
Flow		L/min	30	50	100	150	200	250	300
Working vacuum		MPa	0.08 ~ 0.099
Working Pressure		MPa	≤0.3
Breakdown Voltage		KV	≥75
Water Content		PPM	≤3
Gas Content		%	≤0.01
Impurity Size		μ	≤5
Temperature Range		°C	20 ~ 80
Power			Three Phase 50HZ380V(as per the customer's requirements)
Working Noise		dB(A)	75	75	75	80	80	80	80
Heating Power		kW	30	30	45	60	75	90	120
Total Power		kW	35.5	37.5	52.5	71.4	86.5	102.5	135
Inlet/Outlet		mm	φ25	φ32	φ42	φ50	φ50	φ60	φ60
Weight		kg	600	800	1050	1400	1800	2000	2200
Overall	Length	mm	1050	1100	1200	1450	1600	1800	1900
	Width	mm	750	800	950	950	1100	1200	1200
	Height	mm	1350	1400	1500	1650	1800	1900	1900

Structure Chart:

The oil technical data after treatment:

Gas content less than 0.1%
Impurity size less than 1μm without free carbon
Oil dielectric strength (breakdown voltage) more than 75KV
Acidity value less than 0.01 mgKOH/g
Dielectric loss factors at 90°C less than 0.001

transformer oil filtering's Advantage:

Improved insulation properties of the oil and hence the other media like paper/cellulose insulation
Better the insulation of transformer, longer the life of the transformer and lesser the breakdown of the transformer
Longer the life of the transformer asset, good returns on investment of the asset
Lesser breakdowns and failure of the transformer results in uninterrupted power supply

Packaging & Shipping

Our Services

Your inquiry related to our products or prices will be replied in 24 hours.
Well-trained and experienced staffs to answer all your enquires in fluent English.
Professional service from well-trained and experienced staffs is customers’ best choice to secure good communication, on time delivery, reliable warranty etc.
OEM is available for Anern Products.
Protection of your sales area, ideas of design and all your private information.

Our Customers

FAQ

Q: How can we achieve drying without elevated heating of the insulation material for transformers?
A: Drying of insulation materials can be achieved at low temperature and low pressure levels. The pressure levels and temperature levels for drying vary for distinct material. At low pressure or under vacuum the rate of water vapour evaporation is accelerated if sufficient heat is provided to the insulation material. Thus we can achieve a good drying of insulating material if the material is suitably heated and subjected to vacuum.
