Screw Compressor Unit

Screw Compressor Unit thumbnail-1
Screw Compressor Unit photo-1
US$ 3,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Cooler
Place of Origin:
Jiangsu, China
Brand Name:
AMC
Contact Supplier Request Quote Chat Now
AMC System Technology (Suzhou) Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Cooler
Place of Origin Jiangsu, China
Brand Name AMC
Model Number ASCU-1216
Certification CE, Other, CE, TUV
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. Top brand refrigerating compressor.
2. Complete model & full range.
3. High quality & reliability.
4. Low temperature.

Model of units AMCD30HBZD AMCD40HBZD AMCD50HBZD AMCD60HBZD AMCD70HBZD AMCD80HBZD AMCD90HBZD
Applicable Temperature(°C) -10~-30°C
Refrigerant R22
Power supple 3 8 0 V/ 5 0 H Z
Condenser Form High efficient shell and tube Condenser
Rated water flow(m3/h) 11 15 18 25 27 34 37
Connection Size 2-1/2" 2-1/2" 2-1/2" 3" 4" 4" 4"
Cooling capacity&power Evaporating Temperature Cooling capacity(KW) 36.8 50.2 65.9 87.5 96 119.5 130.7
-20°C Power(KW) 21.5 28.3 35.5 47.3 51.6 61.1 67.2
Evaporating Temperature Cooling capacity(KW) 30.1 41.1 53.8 71.5 78.5 97.7 106.8
-25°C Power(KW) 20.8 27.4 34.4 45.9 50 59.3 65.2
Evaporating Temperature Cooling capacity(KW) 24.3 33.2 43.5 57.7 63.4 79 86.4
-30°C Power(KW) 20.1 26.4 33.2 44.3 48.2 57.1 62.9
Coupling Discharge coupling 54 54 66 76 76 76 108
Suction coupling 28 28 35 35 35 35 42
Overall dimensions Length(A)mm 1700 2150 2300 2600
Width(B) 670 680 770 850
mm
Height(C)mm 1400 1150 1300 1350



Model of units

 AMCD100HBZD AMCD110HBZD AMCD125HBZD AMCD130HBZD AMCD140HBZD AMCD150HBZD
Applicable Temperature(°C) -10~-30°C
Refrigerant R22
Power supple 3 8 0 V/ 5 0 H Z
Condenser Form High efficient shell and tube Condenser
Rated water flow(m3/h) 40 44 52 55 60 65
Connection Size 5" 5" 5" 5" 6" 6"
Cooling capacity&power Evaporating Temperature Cooling capacity(KW) 141.5 155.8 185.5 195.8 214.4 232.1
-20°C Power(KW) 73.4 81.6 94.7 100 108.4 116.7
Evaporating Temperature Cooling capacity(KW) 115.7 127.3 151.6 180 175.2 289.7
-25°C Power(KW) 71.2 79.1 91.9 97 105.1 113.2
Evaporating Temperature Cooling capacity(KW) 93.5 102.9 122.5 129.3 141.6 153.3
-30°C Power(KW) 68.6 76.3 88.6 93.5 101.4 109.1
Coupling Discharge coupling 108 108 108 108 108 108
Suction coupling 42 42 42 42 42 42
Overall dimensions Length(A)mm 2600 2850 3150 3150
Width(B)mm 850 850 850 870
Height(C)mm 1300 1300 1650 1650
