Springconnect F Type Compression Connector Male Plug for RG6 Coaxial Cable Like CX3

Springconnect F Type Compression Connector Male Plug for RG6 Coaxial Cable Like CX3 photo-1
US$ 0.35 - 0.7 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
F compression connector Plug
Model Number:
F compression connector Plug
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Ningbo Guangzhou Qingdao and other Chinese Ports
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Jiangsu, China
Brand Name F compression connector Plug
Model Number F compression connector Plug
Type F
Application RF
Gender Male
Product Description



Springconnect F type compression connector male plug for RG6 Coaxial Cable like CX3  with Class A+ Shielding and permanent continuity

The new SpringConnect Fconnector with excellent mechanical and electrical specifications. Most ordinary push-on connectors have weak pull-off strength and poor screening capabilities resulting in egress/ingress problems. The new SpringConnect is different Corning new SpringConnect comes with  unique plated Secure Spring Technology. The CX3 SpringConnect is safe to use for all regular CATV installations, modem cables, satellite receiver installations and other set-top boxes. The typical disconnect pull-off value from the F-port is more than 3 kg. The continuity is effectively secured and SpringConnect remains RF-tight until it’s completely disconnected.

  • Operational to 3 GHz
  • Impedance 75 Ohm
  • Shielding Efficiency 30 - 1000 MHz >100 dB
  • Transfer Impedance 5-30 MHz <2.5mOhm/mtr
  • Return loss 0.5 – 1000 MHz (typ) 45 dB
  • Return loss 1000 – 3000 MHz (typ) 40 dB
  • IMD (3rd order@2x500mW) -152 dBc
  • IMD (IP3 value) +103 dBm
  • AMP rating cable data
  • Max. Tensile strength (overall) 300 N
  • Waterproof 1 meter/24 hours with additional Seal Ring!
  Another F type compression connector
