High technology portable insulating oil tester, break down voltage testing set
- 100 Set / Sets per Month
- CHONGQING
- T/T Credit Card
Product Details
Place of Origin: | Chongqing, China | Brand Name: | ASSEN | Model Number: | ST-100 |
Power: | Electronic | Usage: | Auto Testing Machine |
Product Description
High technology portable insulating oil tester, break down voltage testing set
ST Insulating oil tester meets the requirement of international standard of IEC-156 and GB507-86<< Insulating oil Dielectric Strength Testing method>> and the feedback of our customers. On the basis of ST-80KV, this device adopts Single-Chip computer, firstly setting the parameter, then test the dielectric strength. The whole process is directed by computer, easily for operating.
1. Adopts automatic test function, this device can operate reset and set the booster return-to-zero automatically.
2. Adopts mini TPU-A panel printer, printing the output data automatically.
3. Testing frequency, blend standing time, acoustic control and optically control remind continues printing or not can be set in accordance to the requirement of the client.
4. Adopts magnon blending technology, this device can eliminate heterogeneous mixing and bubbles.
Breakdown Voltage Tester(BDV Tester) is developed according to the national standard GB-86 Insulating Oil Dielectric Strength Testing Method .The tester can test three cups of oil at the same time LCD screen can display test procedure and test result. All the human interaction operations complete by the rotating mouse .It is very easy for customers to measure the breakdown voltage of all kinds of oil by ASSEN ST-100. You can print the test result by the micro printer internal the tester. Of course, you can upload the test data to PC from RS232 for data analyzing. The special circuit design makes the tester has a good performance at stability and anti-noise.
Insulating oil tester's technical Data:
Measuring range: AC 0-100KV
Rated current: 5mA
Accuracy: 1%
Hi-voltage rate: 2KV/S± 10%
Pre-setting: Frequency 1 - 9
Blending time: 0 - 1 min39s
Standing time: 0 - 10 min39s
Environment temperature: 0 - 45 degree
Relativity Humidity: ≤ 98%
Oil-cup interval: 2.5mm
Dimension: 500*500*500mm
Weight: 28Kg
Insulating oil tester's Structure Chart:
- Your inquiry related to our products or prices will be replied in 24 hours.
- Well-trained and experienced staffs to answer all your enquires in fluent English.
- Professional service from well-trained and experienced staffs is customers’ best choice to secure good communication, on time delivery, reliable warranty etc.
- OEM is available for Anern Products.
- Protection of your sales area, ideas of design and all your private information.
Q: What is BDV test for distribution transformer?
A: When you say BDV you might mean the dielectric strength of transformer oil. A new transformer oil should have at lest a dielectric strength of 39 KV. from a British standard.Transformer oils used are normally tested using ASTM D877-82 with the KV strength tester using 1" electrodes spaced 0.1" apart and the test voltage increased at 3,000 volts/min until it breaks down. The average Kv obtained after 8 trials is considered the Oil dielectric strength.
Using this test method,dielectric strength at 30 kv and above is considered good. Dielectric strength between 23 to 29Kv is considered usable, but requires filtering. Below 23 kv, the transformer oil should be replaced. Another method ASTM D18747-82 uses the small radius electrodes but spaced only .o4 inches. The test voltage is 500volts/min and increased until breakdown. The dielectric strength is still the average Kv obtained in 8 trials. The dielectric strength of 28-29Kv is considered good. Below 28 kv, the transformer oil is usable but requires filtering. The latter method is considered a better test method.
Chongqing Assen Power Equipment Co.,LTD, which is professional in design, manufacture, sale of oil purification equipment, relevant testing instruments and provide comprehensive filtering solution, owns advanced production lines and sophisticated detection equipment, first-class R & D staff , professional workers and High-quality sales and service teams
Our Product: Double Stage Transformer Oil Purification system, Vacuum Lubricating Oil Purification, Vacuum Turbine Oil Conditioner, Portable Oil Purifier, Singe Stage Insulating Oil Purifier, Water Oil Separator, Light fuel Oil Purifier, and Fully-auto Dielectric Oil Tester, Turn ratio Tester, Acid Tester, Moisture Detector, Interfacial Tension Tester, etc.
Our Service: special filter technology consulting and solutions sector; fast after-sale service feedback system, well-trained service engineer; hands-on training and large-scale equipments operation myrmidon; regularly visit system, CRM customer relationship management system; rapid Filter wearing parts and spare parts supply system.
We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
