Oil Dielectric Loss tester with fully automatic touch sreen
This integrated precious insulation oil dielectric loss tester is for measuring dielectric loss TAN and capacitance of transformer insulation oil.This is a high precision instrument; integrated with oil cup, temperature control instrument, temperature sensor, dielectric loss test bridge, AC test power, and standard capacitor, etc.
This integrated precious insulation oil dielectric loss tester is for measuring dielectric loss TAN and capacitance of transformer insulation oil.This is a high precision instrument; integrated with oil cup, temperature control instrument, temperature sensor, dielectric loss test bridge, AC test power, and standard capacitor, etc.
Inside standard capacitor is SF6 tri-pole capacitor whose dielectric loss and capacitance will not be affected by ambient temperature and humidity; Thus ensuring long time high precision test
- Portable type, very light weight, not more than 18kg.
- Equipped with big screen, menu displaying
- Test result can be saved or printed out.
SD-T Insulating oil dielectric loss and resistivity tester, is designed and manufactured based on GB/T5654-2007 of<Liquid insulating material of relative permittivity, dielectric loss factor and DC resistivity measurements>. It is used for measuring dielectric dissipation factor and DC resistivity of insulating oil and other insulating liquids. The instrument is characterized by integrated structure, and integrates test cell, temperature controller, temperature sensor, dielectric loss test bridge, AC test power, standard capacitor, high resistance meter, DC high voltage source and other major components. The instrument adopts full digital technology and all of the intelligent automatic measurement, is equipped with large screen (240*128) LCD display with full Chinese menu, which each step has prompted the Chinese, the test results can be automatically stored and printed output, so that the operator without professional training will be able to use it proficiently
Oil dielectric loss tester's technical Data:
(1) Ambient condition: -5℃~40℃, RH<80%
(2) Power: AC220V +/-10%
(3) HV output voltage: 1000V~2200V
(4) Max. output current: 25mA
(5) Output capacity: 50VA
(6) Precision: 2%
(7) Temperature-control induction oven: max. power 500W
(8) Temperature control range: <100℃
(9) Power: AC220V +/-10%
(10) Temperature measuring error: +/-0.5℃
(11) Temperature control error: +/-1℃
(12) Temperature control duration: ambient to 90℃, less than 20min
(13) Measuring range: tgδ: no limit, Cx: 15pF ~300pF, Rx: 10M-10T
(14) Precision:Δtgδ: +/- (reading x 1.0% + 0.020%),ΔCx: +/- (reading x 1.0% +0.5pF),ΔRx: +/- reading x 10%
(15) Relative permittivity: εr, automatically calculating
(16) PVolume resistivity: ρ, automatically calculating
(17) Dimension: 450 x 310 x 360mm
(18) Weight: 18kg
Oil dielectric loss tester's Structure Chart:
- Your inquiry related to our products or prices will be replied in 24 hours.
- Well-trained and experienced staffs to answer all your enquires in fluent English.
- Professional service from well-trained and experienced staffs is customers’ best choice to secure good communication, on time delivery, reliable warranty etc.
- OEM is available for Anern Products.
- Protection of your sales area, ideas of design and all your private information.
Q: What is BDV test for distribution transformer?
A: When you say BDV you might mean the dielectric strength of transformer oil. A new transformer oil should have at lest a dielectric strength of 39 KV. from a British standard.Transformer oils used are normally tested using ASTM D877-82 with the KV strength tester using 1" electrodes spaced 0.1" apart and the test voltage increased at 3,000 volts/min until it breaks down. The average Kv obtained after 8 trials is considered the Oil dielectric strength.
Using this test method,dielectric strength at 30 kv and above is considered good. Dielectric strength between 23 to 29Kv is considered usable, but requires filtering. Below 23 kv, the transformer oil should be replaced. Another method ASTM D18747-82 uses the small radius electrodes but spaced only .o4 inches. The test voltage is 500volts/min and increased until breakdown. The dielectric strength is still the average Kv obtained in 8 trials. The dielectric strength of 28-29Kv is considered good. Below 28 kv, the transformer oil is usable but requires filtering. The latter method is considered a better test method.
