supply compact backhoe loader xd850 made in china backhoe loader 3cx

FOB Price

USD $10,000 - $30,000 / Unit

1 Unit(Min.Order)

Supply Ability 300 Unit / Units per Month
Port Qingdao or other main ports
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Brand Name:	XIANDAI	Model Number:	XD850
Place of Origin:	Shandong, China	Type:	Front Loader	Moving Type:	Wheel Loader
Dimension(Long * Breadth * High):	740021702950mm	Certification:	CE	Warranty:	12 months
After-sales Service Provided:	Overseas third-party support available

Packaging Details

2 units/40HQ container

Product Description

I.Features&Benefits

1. It has low fuel consumption, low noise and strong power characteristics by using ORIGINAL CUMMINS ENGINE B3.3 (60kw), more efficient and economical, the emission can meet to EURO 3 standard.

2. Adopting main pump PERMCO brand -high quality, long service.

3. JEIL Pilot joystick handler-imported from South Korea, ensure the accuracy and flexibility of each movement.

4. International famous brand front and rear axles same to CARRARO helps steer easily, and the wet brake guarantee the driving and security easily. Efficient hydraulic torque converter provides

ease and great comfort of operation.

5. The super cab is designed with principle of ergonomics to provide the operator a low-noise environment, and possesses fine shock absorption.

6. Hydraulic accessories option: 4-in- 1 bucket, quick coupling plate, driller, forklift, quick hitch,

hydraulic hammer, narrow bucket, tilting bucket.

II.Specifications

General information
Total weight	7000 kg
Overall dimension	7400x2170x2950 mm
Turning radius	3500 mm
Backhoe bucket capacity	0.2-0.3 cbm
Loading bucket capacity	1.0 cbm

Engine
Model	Imported CUMMINS (B3.3)
No. of cylinders, type	4 cylinders in line, Turbo-charged. water cooled
Bore and stroke	102x120 (mm)
Displacement	3.261L
Rated power/rotating speed	60 kw / 2200rpm
Transmission system
Hydraulic torque converter	XN280
Drive Method (2 x 4 or 4 x 4)	4x2 / 4x4
Speed
First forward	6 km/h / 12km/h
Second forward	14.5 km/h / 29km/h
First reverse	6 km/h /12km/h
Second reverse	14.5 km/h / 29km/h
Axle
Axle type	Hub reduction axle
Front axle track	1620 mm
Rear axel track	1340 mm
Hydraulic system
Hydraulic Motor	PERMCO imported from America
Model	3020
Flow rate	80 L/min
Working pressure	22.5 Mpa
Pilot joystick handler	JEIL brand (import from south korea)
Multitandem valve	RUILONG brand
Pilot pump	SKS
Electrical system
Voltage	12 V
Alternator capacity	4 kw
Battery capacity	210 Ah
Front wheels (size & ply rating)	21.5-16
Rear wheels (size & ply rating)	15-24
Diesel fuel tank	125 L
Hydraulic system fluid	132 L
Backhoe part
Backhoe bucket width	560 mm
Backhoe bucket weight	185 kg
Maximum outrigger width (extended)	2900 mm
Minimum outrigger width (transport)	2020 mm
Loader part
Bucket width	2030 mm
Bucket weight	350 kg

Operating range
Loader
A	Maximum bucket reach	3850 mm
B	Maximum loading height	3300 mm
C	Maximum loader dumped height	2550 mm
D	Dumping distance from bucket to fender	810 mm
E	Wheelbase	2110 mm
F	Maximum transport length	7400 mm
G	Maximum digging depth	20-25 mm
H	Ground clearance	300 mm
Backhoe
I	Maximum dumping height	4350 mm
J	Maximum bucket reach	5350 mm
L	Maximum digging depth	4010 mm
M	Maximum digging reach from pivot point	5350 mm
N	Maximum digging reach from rear axle	5467 mm
O	Travel height	3300 mm
P	Height to top of cab	2950 mm
Q	Width	2170 mm

III.Payment terms & Delivery time &GUarantee time

1.Payment Terms : By TT .30% deposit paid in advance, 70% balance paid before goods dispatching from the factory;

2.Delivery Time : within 35 days after receiving deposit;

3.Guarantee Time: one year or 1500 working hours which comes first after the date of B/L;

4.Shipping : 2 units one 40HQ container;
