Specifications
high bucket1.Lifting height: 4.5m
2.Bucket:1.2cbm
3.Full hydraulic control
4.CE certificate
XD918F high bucket
1.China famous brand Sida 4102 engine.
2.Hydraulic transmission and hydraulic steering.
3.Countershaft power-shift gearbox ,torque converter.
4.Air over hydraulic break system ,caliper break system.
5.Wheel reduction axle, automatic bucket flat.
6.Over load protection system
7.Dump height 4.5m
Specification
Model | XD918F |
Bucket capacity (m3 ) | 1.2 |
Rated load (t) | 0.8 |
Weight (t) | 5 |
Lifting time of the arms (s) | ≤6 |
The sum of three items(s) | ≤10 |
Traveling speed (km/h) | 0-18 |
Grade ability | 300 |
Overall length (mm) | 6800 |
Overall width(mm) | 2010 |
Overall height(mm) | 3000 |
Wheel base (mm) | 2600 |
Wheel tread(mm) | 1430 |
Max. dumping height(mm) | 4500 |
Dumping reach (mm) | 1020 |
Engine model | Sida4102 |
Rated power(kw) | 50 |
Rated speed(r/min) | 2400 |
Tire type | 17.5-16 |
