XD918F 4.5M 0.8Ton High Dump Wheel Loader China Agricultural Equipment

Name: XD918F 4.5M 0.8Ton High Dump Wheel Loader China Agricultural Equipment
Brand: XIANDAI
SKU: 102084699

US$ 10,000 - 15,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Brand Name:

XIANDAI

Model Number:

XD918F

Taian Modern Heavy Industries Technology Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao or other main port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name XIANDAI

Model Number XD918F

Place of Origin Shandong, China

Type Front Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 6800*2010*3000MM

Rated Load 0.8T

Certification CE/ CE NOISE /ISO9001

Warranty 12months

After-sales Service Provided Overseas third-party support available

I.Basic Equipment

1.It has the highest dumping height(4.55m) in the world to meet all kinds of truck’s loading.

2.Big capacity bucket(1.2m3) make it load more light materials.

3.Widely used in cotton factory and plastic recycle workshop.

II.Specifications

Model	XD918F
Main specifications
Bucket capacity (m3 )	1.2
Rated load (t)	0.8
Weight (t)	5.0
Lifting time of the arms (s)	≤6
The sum of three items(s)	≤10
Forward gear(km/h)	I 0-8 II 0-18
Reverse gear	I 0-8 II 0-18
Max. climbing gradient	30°
Demensions
Overall dimension (mm)	680020103000
Wheel base (mm)	2600
Wheel tread(mm)	1430
Max. dumping height(mm)	4500
Dumping reach (mm)	1020
Diesel engine
Engine model	YN33
Engine type	In-line,water-cooling,4-stroke,4cylinder,direct-injection
Rated power(kw)	48
Rated speed (r/min)	2400
Total exhaust of cylinder(L)	3.76
Type of starting	Electric start
Transmission system
Torque converter
Model	YJ265
Type	Single stage, three elements
Gearbox
Model	ZL15
Type	Fix counter-shaft, power-shift
Axle and tire
Type of main reducer	Spiral bevel gear,single stage
Type of final reducer	Single stage planetary
Size of tire	17.5-16
Working device of hydraulic system
Model of working pump	CBG2050
Nminal displacement(ml/r)	50
Multi-way directional valve	ZL20
Rated flow(L/min)	15
Steering system
Type	Load-sensing hydraulic steering
Displacement(ml/r)	250
Max input pressure(Mpa)	16
Brake system
Type of traveling break	Air over hydraulic break
Type of parking break	Manual disc break
