Suspension Ceiling Channel System Main channel Furring Channel
1 Material: hot-dipped galvanized steel coil or color-coated steel coil.
2 Size;
main channel
width:38mm/50mm/60mm
height;10MM-27MM
thickness:0.5-1.50mm
length:1000-6000mm
perforated: many pattern for your chice.
furring channel
width:50mm/60mm
height:12mm-27mm
length:1000-6000mm
thickness:0.35-0.70mm
The szie can be order.
3 Packing: naked package
4 Feature:
Easy installation way
Using tenons to instead traditional parts installing Carrying Channel and Furring bar.
Efficient work to save working time and money
Using tenon and less acccessories, save your working time and expense.
Different demands of loading capacity
Using the combination of different installation distance and product dimension reach the request of loading capacity.
| main channel | DZ38 | 38*(10-12)*3000mm |
| DZ50 | 50*(12-15)*3000mm | |
| DZ60 | 60*(20-27)*3000mm | |
| furring channel | DF50 | 50*(12,17,20)*3000mm |
| DF60 | 60*(24,27)*3000mm | |
| side channel | DU20 | (50,60)*(20,30)*3000mm |
| corner anger | DL30 | 30*(10-12)*3000mm |
Specifications
1. Our production is made by the good quality materials and professional work teams
2. It is with nice looking and easy to install to save time and coast.
3. We can make any size by your orders
Advantage
1. Galvanized steel profile raw material is high quality hot dipped zinc galvanized steel strip, absolute damp proofing, heat insulation and high durability, high rust resistance.
2. The specification can follow up customer requirements.
3. Advanced equipment can make sure exactly size, high quality products.
Tips:
If you have any special requirement, please advise us the length, width, height and the thickness, also the quantity. Thanks
We are 19 year manufacturer, Product apply in: Asia, Mid East, Europe, South America, Africa, Australia and so on.
Quality inspection procedure
1. We have five strict QC processes including incoming materials QC, IPQC (in process QC on patrol), LQC (line QC), FQC (final product QC) and OQC (output QC before shipping).
2. High quality 1100 aluminum alloy or galvanized steel.
Payment
T/T 30% deposit and 70% must be pay before shipment.
Delivery time
7-14 days
Packing
Naked package (Our logo , your logo, or not logo)
After service
If you find any product problems in the first order, we will give you the new parts for free to replace in the next order.
The product photos show
The factory shows
