Wholesaling and Retail Charcoal Briquette Press Machine / Coal Briquette Making Machine / Coal Dust Briquette Machine

Wholesaling and Retail Charcoal Briquette Press Machine / Coal Briquette Making Machine / Coal Dust Briquette Machine photo-1
US$ 2,500 - 110,300 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Production Capacity:
1-70 t/h
Motor Type:
AC Motor
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao tianjin shanghai or others
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Production Capacity 1-70 t/h
Motor Type AC Motor
Power(W) 7.5kw-130 kw
Place of Origin Henan, China
Brand Name weilite
Model Number WLXM coal dust briquette machine
Dimension(L*W*H) smallest :1600*1050*1400,etc
Certification ISO9001:2008 ,SGS
Warranty 1year (no include wearing parts)
After-sales Service Provided Engineers available to service machinery overseas

Specifications

coal dust briquette machine
1. size required: less than 5mm;
2. moisture required: 8%-12%;
3. capacity : 1-70 t per hour

                      coal dust briquette machine



wholesaling and retail charcoal briquette press machine / coal briquette making machine / coal dust briquette machine



Product Description

Suitable materials for the coal dust briquette machine

This kind of briquette machine is mainly used to press charcoal powder/charcoal dust, coal dust, carbon dust/carbon powder, activated carbon, bamboo carbon powder, coke powder, shisha carbon, graphite powder, semi coke powder and other powders, or waste material.

Shape of the finished briquettes of the coal dust briquette machine

The shape can be square ,oval, pillow,etc.

Range of applications for the coal dust briquette machine

Widely used in refractory material, power plants, metallurgical, chemical, energy, transportation, heating, animal husbandry, industry, agriculture, barbecue, and other fields.



wholesaling and retail charcoal briquette press machine / coal briquette making machine / coal dust briquette machine wholesaling and retail charcoal briquette press machine / coal briquette making machine / coal dust briquette machine wholesaling and retail charcoal briquette press machine / coal briquette making machine / coal dust briquette machine



The working principle of the coal dust briquette machine

The charcoal/coal briquette machine is consisted mainly by the electrical machine, reducer,main machine, belt conveyor, alignment system of the roller shell,hydraulic system,electronic control,etc. the material enter into the area between the two compression roller by the action of gravity from the feeding hole. There are many same size roll groove in the two roll surface,with the constant speed and opposite direction run,the material has been compress mandatory,as the roll continue to run ,the pressed ball drop down.

Repair and Accident Disposing of the coal dust briquette machine

    (1).The maintain and check of the machine is essential . Regularly check the tightness of the safety bolts, oil mass, motor current, temperature rise of the bearings, the running of the v-belt and the tank’s oil pressure. When checking the oil pressure, please stop the machine. If any pressure changes cause by temperature changing or oil spill, new oil should be filled or let oil return to correct the pressure. If oil spills from the oil pressure system when the machine is running, please restart the machine after the problem is solved.

    No matter how careful you are when running the machine, abrasion of wearing parts and bearings can not be avoided. General speaking, the machine is in the dusty environment, stop the machine and do regularly checking on the inside parts is necessary. If possible check it every three months or every half a year and you will know the condition of the all the parts.



FAQ

Easy-to-damage Parts of the coal dust briquette machine

(1) Rolling Bearings

(2) Roller and Vice roller

(3) Material Mouth

(4) triangle belt



Technology parameters for the coal dust briquette machine



Model

WLXM-360

WLXM-400

WLXM-500

WLXM-650

WLXM-750

WLXM-850

WLXM-1250

Capacity

2~4 t/h

6~8t/h

8~11t/h

13~18 t/h

18~25t/h

25~35 t/h

40~70 t/h





Motor power

7.5 kw

11~15kw

18.5~22kw

20~30 kw

45kw

75 kw

130 kw

Rotation speed

18 r/min.

15r/min.

13r/min

13 r/min.

13r/min

10 r/min.

10 r/min.

Shapes of briquettes

Oval or pillow or square or customized

Sizes of briquettes

As your specific requirement ( usually 20~80mm )




   wholesaling and retail charcoal briquette press machine / coal briquette making machine / coal dust briquette machine wholesaling and retail charcoal briquette press machine / coal briquette making machine / coal dust briquette machine

Our Services

 User Right for the coal dust briquette machine

(1).We only supply foundation drawing, if any more requirements on drawing, please order in advance.

(2).Hope our customer will feedback the usage condition, to gain more further cooperation and improvement for both of us.





Packaging & Shipping

 coal dust briquette machine

Based on the actual situation
single machine use wooden case in general
for the whole production line in container





  wholesaling and retail charcoal briquette press machine / coal briquette making machine / coal dust briquette machine wholesaling and retail charcoal briquette press machine / coal briquette making machine / coal dust briquette machine wholesaling and retail charcoal briquette press machine / coal briquette making machine / coal dust briquette machine wholesaling and retail charcoal briquette press machine / coal briquette making machine / coal dust briquette machine



Company Information



Zhengzhou Weilite Machinery Equipment Co., Ltd. is an export and manufacturing oriented enterprise . Our company produce large ,medium and small capacity/output beneficiation production line , sand making production line and briquette making production line with over 30 years for the oversea market .

 wholesaling and retail charcoal briquette press machine / coal briquette making machine / coal dust briquette machinewholesaling and retail charcoal briquette press machine / coal briquette making machine / coal dust briquette machine



I am Ms. Ashley , any questions about the coal dust briquette machine, contact me freely by email or online talk, thank you very much for your consideration , Skype: ashley.weilite .
